广州研华工业主板AIMB-580 ATX 母板 Q57 芯片组
嵌入式主板&设计服务 /
工业母板 /
MicroATX 母板 /
AIMB-580 /
支持Intel® Core™ i7/i5/i3/Pentium 处理器，采用Q57 芯片组
4个 DIMM 插槽支持高达 16 GB DDR3 800/1066/1333内存
支持VGA和DVI双显，双千兆网口
支持SATA RAID 0, 1, 5, 10, AMT 6.0, TPM 1.2 (可选)
支持嵌入式软件API和Utilities
| AIMB-580QG2-00A1E | AIMB-580WG2-00A1E | ||
|---|---|---|---|
| Quote Build | Quote | ||
| Form Factor | Form Factor | Micro ATX | Micro ATX |
| Processor | CPU | Intel i7-860 / i5-750 / i5-660 / i3-540/ Pentium G6950 | Intel Xeon 3450 / Core i5-660 / i3-540/ Pentium G6950 |
| CPU TDP | 95W / 73W | 95W / 65W | |
| Frequency | 2.66GHz ~ 3.3 GHz | 2.66GHz ~ 3.3 GHz | |
| Core Number | 2 / 4 | 2 / 4 | |
| L3 Cache | 3 ~ 8MB | 3 ~ 8MB | |
| BIOS | AMI EFI 64Mbit | AMI EFI 64Mbit | |
| Chipset | Intel Q57 PCH | Intel 3450 PCH | |
| Memory | Technology | DDR3 800/1066/1333 MHz | DDR3 800/1066/1333 MHz |
| Max. Capacity | 16 GB | 16 GB | |
| ECC Support | No | Yes | |
| Socket | 4 x 240-pin DIMM | 4 x 240-pin DIMM | |
| Display | Controller | Intel HD Graphics | Intel HD Graphics |
| Graphic Engine | DirectX 10 ａnd Open GL 2.1 supported | DirectX 10 ａnd Open GL 2.1 supported | |
| Graphic Memory | 1GB maximum shared memory with 2GB ａnd above system memory installed | 1GB maximum shared memory with 2GB ａnd above system memory installed | |
| VGA | Up to 2048 x 1563 @ 60Hz | Up to 2048 x 1563 @ 60Hz | |
| DDI (HDMI/DVI/DisplayPort) | DVI: 1920 x 1200 @ 60Hz | DVI: 1920 x 1200 @ 60Hz | |
| Multiple Display | Dual | Dual | |
| Expansion | PCI Express x 16 | 1 | 1 |
| PCI Express x 4 | 1 | 1 | |
| PCI | 2 | 2 | |
| LPC | 1 | 1 | |
| Ethernet | Controller | GbE1: Intel 82578DM GbE2: Intel 82583V | GbE1: Intel 82578DM GbE2: Intel 82583V |
| Speed | 10/ 100/ 1000 Mbps | 10/ 100/ 1000 Mbps | |
| Connector | RJ45 x 2 | RJ45 x 2 | |
| Audio | Audio Interface | HD Audio | HD Audio |
| CODEC | Realtek ALC892, High Definition Audio (HD) | Realtek ALC892, High Definition Audio (HD) | |
| Connector | 2 (Line out, Mic-in) | 2 (Line out, Mic-in) | |
| Watchdog Timer | WatchDog Timer | Yes | Yes |
| Storage | SATA | 6 x SATAII (Max. Data Transfer Rate 300 MB/s) | 6 x SATAII (Max. Data Transfer Rate 300 MB/s) |
| RAID | Software RAID 0, 1, 5, 10 | Software RAID 0, 1, 5, 10 | |
| I/O | USB2.0 | 10 | 10 |
| LPT | 1 | 1 | |
| COM Port | 4 ( 3 x RS232, 1 x RS232/ 422/ 485) | 4 ( 3 x RS232, 1 x RS232/ 422/ 485) | |
| Keypad | 1 | 1 | |
| TPM | Optional | Optional | |
| Smart Fan | 3 | 3 | |
| Power | Power Type | ATX | ATX |
| Connector | ATX24P | ATX24P | |
| Power Consumption (Idle) | 1.82A @ 5V / 0.64A @ 3.3V / 1.48A @ 12V / 0A @ 5Vsb / 0A @ -12V | 1.8 @ 5V / 0.91A @ 3.3V / 2.84A @ 12V / 0.06A @ 5Vsb / 0.12A @ -12V | |
| Power Consumption (Full Load) | 1.8A @ 5V / 0.67A @ 3.3V / 3.5 @ 12V / 0.01A @ 5Vsb / 0A @ -12V | 2.8A @ 5V / 0.99A @ 3.3V / 5.14A @ 12V / 0.01A @ 5Vsb / 0.13A @ -12V | |
| Battery | Lithium 3 V / 200 mAh | Lithium 3 V / 200 mAh | |
| Environment | Operational Temperature | 0 ~ 60° C (32 ~ 140° F) (Operational humidity: 40° C @ 95% RH Non-Condensing) | 0 ~ 60° C (32 ~ 140° F) (Operational humidity: 40° C @ 95% RH Non-Condensing) |
| Non-Operational Temperature | -20 ~ 70° C (-4 ~ 158F) ａnd 60° C @ 95% RH Non-Condensing | -20 ~ 70° C (-4 ~ 158F) ａnd 60° C @ 95% RH Non-Condensing | |
| Vibration Resistance | 3.5 Grm (Non-Operation Mode) | 3.5 Grm (Non-Operation Mode) | |
| Physical | Dimension (mm) | 244 x 244 mm | 244 x 244 mm |
| Weight | 1.2 kg (2.64 lb), weight of total package | 1.2 kg (2.64 lb), weight of total package | |
| Operating System | Microsoft Windows | Yes | Yes |
| Linux | Yes | Yes | |
| SUSIAccess | Yes | Yes | |
| Certification | EMC | CE, FCC | CE, FCC |
