pco.dimax HS4
highest frame rates for extreme fast events
The pco.dimax HS series combines, with its advanced CMOS- ａnd electronics technology, extreme high frame-rates, best light sensitivity ａnd a real 12 bit dynamic range.
With more than 7000 fps at a resolution of 1 megapixel rapid events can be precisely imaged in super slow motion. Due to a variety of trigger- ａnd synchronization possibilities the HS-cameras are suitable for challenging setups like engine research, flow analysis, material testing ａnd further application areas.
For further information see product data sheet.
All products at a glance - the new high-speed product overview.
2277 fps @ 4 MPix resolution (2000 x 2000 pixel)
7039 fps @ 1 MPix resolution (1000 x 1000 pixel)
excellent light sensitivity
12 bit dynamic range
NO additional black reference calibration required
9, 18, 36 GB inbuilt image memory
exposure time range 1.5 µs - 40 ms
multiple trigger options
master-slave camera synchronisation (up to 5 cameras)
IRIG B timecode function
Interfaces: USB 3.0, GigE/USB 2.0, HD-SDI, CameraLink
