X-ring星型圈美制as568现货库存进口胶料NBR
- 产地：中国大陆
- 供应商：上海润狮实业有限公司
- 供应商报价：电议
- 标签：X-ring星型圈美制as568现货库存进口胶料NBR,常用仪表,阀门仪表,供应X-ring星型圈美制as568现货库存进口胶料NBR,上海润狮实业有限公司
产品库
| RUNLION X-RING |
| 标准：AS568系列 | |
| 内径 | 公差 | 线径 | 公差 |
| （ID） | （±） | （C/S） | （±） |
| 2.90-6.29 | 0.13 | 0-1.79 | 0.07 |
| 6.30-10.59 | 0.14 | 1.80-2.64 | 0.08 |
| 10.60-18.99 | 0.17 | 2.65-3.54 | 0.09 |
| 19.00-31.49 | 0.22 | 3.55-5.29 | 0.10 |
| 31.50-41.19 | 0.30 | 5.30-6.99 | 0.13 |
| 41.20-51.49 | 0.36 | 7.00-8.00 | 0.15 |
| 51.50-64.99 | 0.44 | 8.01-10.00 | 0.20 |
| 65.00-82.49 | 0.53 | 10.01-15.00 | 0.25 |
| 82.50-121.99 | 0.65 | 15.01-25.00 | 0.35 |
| 122.00-184.99 | 0.90 | 24.01-100.00 | 0.45 |
| 185.00-257.99 | 1.20 |
|
|
| 258.00-324.99 | 1.60 |
|
|
| 325.00-411.99 | 2.10 |
|
|
| 412.00-514.99 | 2.60 |
|
|
| 515.00-649.99 | 3.20 |
|
|
| 650.00-670.00 | 4.00 |
|
|
| 670.10-999.00 | 5.00 |
|
|
| 999.00-1200.00 | 6.00 |
|
|
| 1200.01-1500.00 | 7.00 |
|
|
| 1500.01-1800.00 | 8.00 |
|
|
| 1800.01-2000.00 | 9.00 |
|
|
| 内径d1 | 线径d2 |
| 内径d1 | 线径d2 |
| 内径d1 | 线径d2 |
| 内径d1 | 线径d2 |
| 240.89 | 3.53 | 85.09 | 5.33 | 380.37 | 5.33 | 354.97 | 7.00 | |||
| 247.24 | 3.53 | 88.27 | 5.33 | 405.26 | 5.33 | 367.67 | 7.00 | |||
| 253.59 | 3.53 | 91.44 | 5.33 | 430.66 | 5.33 | 380.37 | 7.00 | |||
| 266.29 | 3.53 | 94.62 | 5.33 | 456.06 | 5.33 | 393.07 | 7.00 | |||
| 278.99 | 3.53 | 97.79 | 5.33 | 481.38 | 5.33 | 405.26 | 7.00 | |||
| 291.69 | 3.53 | 100.97 | 5.33 | 506.78 | 5.33 | 417.96 | 7.00 | |||
| 304.39 | 3.53 | 104.14 | 5.33 | 532.18 | 5.33 | 430.66 | 7.00 | |||
| 329.79 | 3.53 | 107.32 | 5.33 | 557.58 | 5.33 | 443.36 | 7.00 | |||
| 355.19 | 3.53 | 110.49 | 5.33 | 582.68 | 5.33 | 456.06 | 7.00 | |||
| 380.59 | 3.53 | 113.67 | 5.33 | 608.08 | 5.33 | 468.76 | 7.00 | |||
| 405.26 | 3.53 | 116.84 | 5.33 | 633.48 | 5.33 | 481.46 | 7.00 | |||
| 430.66 | 3.53 | 120.02 | 5.33 | 658.88 | 5.33 | 494.16 | 7.00 | |||
| 456.06 | 3.53 | 123.19 | 5.33 | 113.67 | 7.00 | 506.86 | 7.00 | |||
| 10.46 | 5.33 | 126.37 | 5.33 | 116.84 | 7.00 | 532.26 | 7.00 | |||
| 12.07 | 5.33 | 129.54 | 5.33 | 120.02 | 7.00 | 557.66 | 7.00 | |||
| 13.64 | 5.33 | 132.72 | 5.33 | 123.19 | 7.00 | 582.68 | 7.00 | |||
| 15.24 | 5.33 | 135.89 | 5.33 | 126.37 | 7.00 | 608.08 | 7.00 | |||
| 16.81 | 5.33 | 139.07 | 5.33 | 129.54 | 7.00 | 633.48 | 7.00 | |||
| 18.42 | 5.33 | 142.24 | 5.33 | 132.72 | 7.00 | 658.88 | 7.00 | |||
| 19.99 | 5.33 | 145.42 | 5.33 | 135.89 | 7.00 |
|
| |||
| 21.59 | 5.33 | 148.59 | 5.33 | 139.07 | 7.00 |
|
| |||
| 23.16 | 5.33 | 151.77 | 5.33 | 142.24 | 7.00 |
|
| |||
| 24.77 | 5.33 | 158.12 | 5.33 | 145.42 | 7.00 |
|
| |||
| 26.34 | 5.33 | 164.47 | 5.33 | 148.59 | 7.00 |
|
| |||
| 27.94 | 5.33 | 170.82 | 5.33 | 151.77 | 7.00 |
|
| |||
| 29.51 | 5.33 | 177.17 | 5.33 | 158.12 | 7.00 |
|
| |||
| 31.12 | 5.33 | 183.52 | 5.33 | 164.47 | 7.00 |
|
| |||
| 32.69 | 5.33 | 189.87 | 5.33 | 170.82 | 7.00 |
|
| |||
| 34.29 | 5.33 | 196.22 | 5.33 | 177.17 | 7.00 |
|
| |||
| 37.47 | 5.33 | 202.57 | 5.33 | 183.52 | 7.00 |
|
| |||
| 40.64 | 5.33 | 208.92 | 5.33 | 189.87 | 7.00 |
|
| |||
| 43.82 | 5.33 | 215.27 | 5.33 | 196.22 | 7.00 |
|
| |||
| 46.99 | 5.33 | 221.62 | 5.33 | 202.57 | 7.00 |
|
| |||
| 50.17 | 5.33 | 227.97 | 5.33 | 215.27 | 7.00 |
|
| |||
| 53.34 | 5.33 | 234.32 | 5.33 | 227.97 | 7.00 |
|
| |||
| 56.52 | 5.33 | 240.67 | 5.33 | 240.67 | 7.00 |
|
| |||
| 59.69 | 5.33 | 247.02 | 5.33 | 253.37 | 7.00 |
|
| |||
| 62.87 | 5.33 | 253.37 | 5.33 | 266.07 | 7.00 |
|
| |||
| 66.04 | 5.33 | 266.07 | 5.33 | 278.77 | 7.00 |
|
| |||
| 69.22 | 5.33 | 278.77 | 5.33 | 291.47 | 7.00 |
|
| |||
| 72.39 | 5.33 | 291.47 | 5.33 | 304.17 | 7.00 |
|
| |||
| 75.57 | 5.33 | 304.17 | 5.33 | 316.87 | 7.00 |
|
| |||
| 78.74 | 5.33 | 329.57 | 5.33 | 329.57 | 7.00 |
|
| |||
| 81.92 | 5.33 | 354.97 | 5.33 | 342.27 | 7.00 |
|
| |||
| 内径d1 | 线径d2 |
| 内径d1 | 线径d2 |
| 内径d1 | 线径d2 |
| 内径d1 | 线径d2 |
| 240.89 | 3.53 | 85.09 | 5.33 | 380.37 | 5.33 | 354.97 | 7.00 | |||
| 247.24 | 3.53 | 88.27 | 5.33 | 405.26 | 5.33 | 367.67 | 7.00 | |||
| 253.59 | 3.53 | 91.44 | 5.33 | 430.66 | 5.33 | 380.37 | 7.00 | |||
| 266.29 | 3.53 | 94.62 | 5.33 | 456.06 | 5.33 | 393.07 | 7.00 | |||
| 278.99 | 3.53 | 97.79 | 5.33 | 481.38 | 5.33 | 405.26 | 7.00 | |||
| 291.69 | 3.53 | 100.97 | 5.33 | 506.78 | 5.33 | 417.96 | 7.00 | |||
| 304.39 | 3.53 | 104.14 | 5.33 | 532.18 | 5.33 | 430.66 | 7.00 | |||
| 329.79 | 3.53 | 107.32 | 5.33 | 557.58 | 5.33 | 443.36 | 7.00 | |||
| 355.19 | 3.53 | 110.49 | 5.33 | 582.68 | 5.33 | 456.06 | 7.00 | |||
| 380.59 | 3.53 | 113.67 | 5.33 | 608.08 | 5.33 | 468.76 | 7.00 | |||
| 405.26 | 3.53 | 116.84 | 5.33 | 633.48 | 5.33 | 481.46 | 7.00 | |||
| 430.66 | 3.53 | 120.02 | 5.33 | 658.88 | 5.33 | 494.16 | 7.00 | |||
| 456.06 | 3.53 | 123.19 | 5.33 | 113.67 | 7.00 | 506.86 | 7.00 | |||
| 10.46 | 5.33 | 126.37 | 5.33 | 116.84 | 7.00 | 532.26 | 7.00 | |||
| 12.07 | 5.33 | 129.54 | 5.33 | 120.02 | 7.00 | 557.66 | 7.00 | |||
| 13.64 | 5.33 | 132.72 | 5.33 | 123.19 | 7.00 | 582.68 | 7.00 | |||
| 15.24 | 5.33 | 135.89 | 5.33 | 126.37 | 7.00 | 608.08 | 7.00 | |||
| 16.81 | 5.33 | 139.07 | 5.33 | 129.54 | 7.00 | 633.48 | 7.00 | |||
| 18.42 | 5.33 | 142.24 | 5.33 | 132.72 | 7.00 | 658.88 | 7.00 | |||
| 19.99 | 5.33 | 145.42 | 5.33 | 135.89 | 7.00 |
|
| |||
| 21.59 | 5.33 | 148.59 | 5.33 | 139.07 | 7.00 |
|
| |||
| 23.16 | 5.33 | 151.77 | 5.33 | 142.24 | 7.00 |
|
| |||
| 24.77 | 5.33 | 158.12 | 5.33 | 145.42 | 7.00 |
|
| |||
| 26.34 | 5.33 | 164.47 | 5.33 | 148.59 | 7.00 |
|
| |||
| 27.94 | 5.33 | 170.82 | 5.33 | 151.77 | 7.00 |
|
| |||
| 29.51 | 5.33 | 177.17 | 5.33 | 158.12 | 7.00 |
|
| |||
| 31.12 | 5.33 | 183.52 | 5.33 | 164.47 | 7.00 |
|
| |||
| 32.69 | 5.33 | 189.87 | 5.33 | 170.82 | 7.00 |
|
| |||
| 34.29 | 5.33 | 196.22 | 5.33 | 177.17 | 7.00 |
|
| |||
| 37.47 | 5.33 | 202.57 | 5.33 | 183.52 | 7.00 |
|
| |||
| 40.64 | 5.33 | 208.92 | 5.33 | 189.87 | 7.00 |
|
| |||
| 43.82 | 5.33 | 215.27 | 5.33 | 196.22 | 7.00 |
|
| |||
| 46.99 | 5.33 | 221.62 | 5.33 | 202.57 | 7.00 |
|
| |||
| 50.17 | 5.33 | 227.97 | 5.33 | 215.27 | 7.00 |
|
| |||
| 53.34 | 5.33 | 234.32 | 5.33 | 227.97 | 7.00 |
|
| |||
| 56.52 | 5.33 | 240.67 | 5.33 | 240.67 | 7.00 |
|
| |||
| 59.69 | 5.33 | 247.02 | 5.33 | 253.37 | 7.00 |
|
| |||
| 62.87 | 5.33 | 253.37 | 5.33 | 266.07 | 7.00 |
|
| |||
| 66.04 | 5.33 | 266.07 | 5.33 | 278.77 | 7.00 |
|
| |||
| 69.22 | 5.33 | 278.77 | 5.33 | 291.47 | 7.00 |
|
| |||
| 72.39 | 5.33 | 291.47 | 5.33 | 304.17 | 7.00 |
|
| |||
| 75.57 | 5.33 | 304.17 | 5.33 | 316.87 | 7.00 |
|
| |||
| 78.74 | 5.33 | 329.57 | 5.33 | 329.57 | 7.00 |
|
| |||
| 81.92 | 5.33 | 354.97 | 5.33 | 342.27 | 7.00 |
|
|
