WIKA DI10 面板安装式数显仪 电流输出4-20mA 96*98mm 精度0.3

产品信息
WIKA DI10 面板安装式数显仪 电流输出4-20mA 96*98mm 精度0.3



加工定制： 是 防护等级： IP65
测量范围： -1999-9999（kPa） 类型： 数字压力变送器
防爆等级： 无 型号： DI10
测量介质： 液体 气体 精度等级： 0.3
品Pai： WIKA/威卡 输出信号： 4-20（mA）
电源电压： 10-30（V）

WIKA DI10 面板安装式数显仪 电流输出4-20mA 96*98mm 精度0.3

Digital indicator for panel mounting
Model DI10




Digital indicator model DI10
Fig. top: for panel mounting
Fig. bottom: for wall mounting



   Applications
     Machine building ａnd plant construction
     Test benches
     Level measurement
     General industrial applications


   Special features
     Suitable for 4 ... 20 mA current loops
     Min/Max value memory
     Linearisation with up to 10 programmable points
     2 optional potential-free switch contacts
     Minimal mounting depth: 25 mm without plug-in terminal







   Description
    The DI10 digital indicator, with its small mounting depth, is ideally suited for mounting in applications with limited mounting space. As a result of this small insertion depth, it can be used in applications where other indicators would be too
large.


    The digital indicator is suitable for industry-standard 4 ... 20 mA current loop signals. The power supply for the display comes directly from the current loop, so no additional power supply is needed.


    The display is parameterised through a logically-structured menu which enables intuitive operation. The settings can be made using the control keys on the front.


    The parameterisation enables the setting of the indication range ａnd an offset. In addition, a sensor signal can be

linearised with up to 10 programmable points. The display time can be varied between 0.1 ａnd 10 seconds. In order to prevent unintentional changes by the operator within the menu system, a programming lock can be activated.




    The retrieval of the Min/Max values is made through the simple operation of the control keys.


    Two PhotoMOS outputs are available as options, with adjustable hysteresis independent of each other.


    For convenient installation outside of electrical panels, the display is also available in a practical wall-mount enclosure, which offers an ingress protection of IP 65.







   Specifications
    Model DI1



   Dimensions in mm
    Panel-mount unit



   Designation of terminal connectors
