DK系列 电热恒温水槽、水浴锅 DK S eries Water Bath
DKB-501S 超级恒温水槽 DKB High precision Water Bath
一、 用途概述：
供大专院校、工矿企业和科研单位等作精密恒温和辅助加热之用。
二、 产品特点：
1、 采用不锈钢内胆、顶盖。
2、 微电脑智能控温仪，具有设定、测定温度双数字显示和PID自整功能，控温精确、可靠。
3、 带内置循环水泵的产品，在加装外循环接口后，可向外输出恒温水流。
I .applications:
Suitable for incubation and thermal treatment in different fields of applications .
II .Features:
1、 The working chamber and the lid are made of stainless steel.
2、 Intelligent temperature controller is based microprocessor with PID parameters controlling function .Digital display of set and actual temperatures. High temperature controlling accuracy and reliability.
3、 If product that has the inner circle water pumps, after install the outer circle, it can be output the constant temperature water
三、 技术参数。(Specifications):
产品名称Product | 电热恒温水槽Water Bath | 三用恒温水箱Water Bath (three ways ) | 超级恒温水槽 High precision Water Bath | 型号 Model 出厂价（元） | DK-420 1290 | DK-600 1590 | DKB-8A 2380 | DK-8B 1680 | DK-420S 1360 | DK-600S 1760 | DKB-501S 3660 | 电源电压Mains voltage | 220V.50Hz | 控温范围Temperature control range | RT+5～65 ℃ | RT+5～100 ℃ | 温度波动Temperature fluctuation | ±0.5℃ | ±0.1℃ | ±0.5℃ | ±0.1℃ | 消耗功率Consumption Power | 500W | 1000W | 1500W | 700W | 1800W | 750W | 水泵流量Flux water pump | | 4L/min | | 4L/min | 工作室尺寸Dimensions of the working chamber | 420×180× 110mm | 600×300× 150mm | 500*300*150mm | 5000×300×135mm | 420×180×110mm | 600×300×150mm | 300*240*150mm |
产品名称Product | 电热恒温水锅Electric Water Bath | 电热恒温水槽Water Bath | 型号Model | DK –S22 | DK-S24 | DK-S26 | DK-S28 | DK-8D | 电源电压Mains voltage | 220V.50Hz | 控温范围Temperature control range | RT+5～100 ℃ | 温度波动Temperature fluctuation | ±0.5℃ | 消耗功率Consumption Power | 500W | 800W | 1500W | 2000W | 750W | 工作室尺寸Dimensions of the working chamber | 240*150*110mm | 300*240*110mm | 500*300*110mm | 600 × 300 × 110mm | 152 × 126 × 110mm × 3 | 备注Remark | 双孔Two-place | 双列四孔Two-rowFour-place | 双列六孔Two-rowSix-place | 双列八孔Two-rowEight-place | 三孔三温Three-placeThree-tempeature |
|
