BXC【防爆检修电源插座箱】(ⅡB、ⅡC)-出厂价/生产价找三诺厂商

产品信息
乐清市三诺防爆电气有限公司是专业生产防爆电气,价格实惠、质量保证 、产品外形美观。欢迎新老客户来电。

BXC防爆检修电源插座箱(ⅡB、ⅡC)
BXC Explosion-Proof, Maintaining, Power Sources Socket Box (ⅡB、ⅡC)


1. 爆炸性气体环境危险场所:1区、2区;
2. 可燃性气体、蒸气级别:ⅡA、ⅡB、ⅡC;
3. 温度组别:T1~T6;
4. 户内、户外(IP54)。

1. For the dangerous sites with explosive air mixture:
1 division, 2 division;
2. Flammable gas, steam class: ⅡA、ⅡB、ⅡC;
3. Temperatures classification: T1~T6;
4. Indoor and outdoor (IP54).










1. 铸铝合金外壳,表面喷塑;
2. 插座上带有分合指示;
3. 支路极数及电流可混合设置,便于检修用电源;
4. 可带有总开关及带漏电保护分开关,具有过载,
短路保护功能;
5. 可根据用户要求特制;
6. 符合GB3836-2000、IEC60079, GB12476.1-2000、
IEC61241标准要求。

1. Diecasted of Al-alloy shell with and plastic-sprayed surface;
2. Socket has open-close indicator;
3. Branch pole number and current mixed divice is convenient to maintain current;
4. Can be matched with general switch for protecting the circuit from the damages of overload and short;
5. Can be customized according to users requirements.
6. Suitabe for GB3836-2000、IEC60079、GB12476.1-2000、IEC61241 standard request.


支路数
Branch
number
额定电流
Rated
current(A)
输入电压
Input
voltage
输入电源
Input power
source
输出电压
Output
voltage (V)
输出电源
Output power
source
防爆标志
Explosion-
proofing marker
防腐等级
osion-proofing
grade
防护等级
Protection
category
2, 3, 4, 6
8, 9, 10
15, 30
AC380
3P+N+PE
AC380±10%
3P+PE
Exde ⅡBT6
Exde ⅡCT6
W, WF1, WF2
IP54
AC220±10%
1P+N+PE
