HRMS-45型数显表面洛氏硬度计
- 型号：HRMS-45型
- 产地：上海
- 供应商：宁波市镇海佰亿计量检测仪器有限公司
- 供应商报价：23000
- 标签：HRMS-45型数显表面洛氏硬度计,供应HRMS-45型数显表面洛氏硬度计,宁波市镇海佰亿计量检测仪器有限公司
产品库
HRMS-45型数显表面洛氏硬度计，是一种较为先进，采用大屏幕显示和操作的数字式显示硬度值的表面洛氏硬度计。通过大屏幕触摸操作，可对表面洛氏硬度标尺进行选择，数字式显示测试数据，各种硬度值之间的换算。并具有对测试数据储存、打印输出、RS-232超级终端设置等功能，本机具有很好的稳定性和直观性。
适用范围
表面淬火钢，材料表面热处理和化学处理，铜、铝合金等薄板，镀锌、镀铬、镀锡材料，轴承钢，冷硬铸件等。
HRMS-45 Digital Superficial Rockwell Hardness Tester adopts novel-designed large LCD screen to display, as well as menu structure. It mainly functions are as follows: 1. Selection of Rockwell hardness scales, 2. Exchange hardness values among hardness scales, 3. Output the results of hardness measurement with printer, 4. RS-232 hyper terminal setting is with good reliability, excellent operationeasy watching.
Usage Range:
Surface hardened steel, surface heat treatingchemical treating materials, copper, aluminum alloy sheet, zinc layers, chrome layers, tin layers, bearing steel, coldhard casting parts, etc.
表面洛氏标尺 Superficial Rockwell Scales | HR15N, HR30N, HR45N, HR15T, HR30T, HR45T |
初试验力Initial Testing Force） | 3Kg 29.42N |
试验力Testing Force | 15Kg 147.1N, 30Kg 294.2N, 45Kg 441.3N |
转换标尺 Exchange Scales | 洛氏、布氏、维氏 Superficial Rockwell, Brinell, Vickers |
硬度读取Indication of Hardness Value | 大屏幕数字显示 Digital Display with Large LCD Screen |
数据输出Data Output | 内置打印机和RS-232接口 Inside PrinterRS-232 Interface |
保荷时间Duration Time | 0~60S |
试件高度Max Height of Specimen | 170mm |
仪器尺寸Overall Dimension | 520×240×720mm （长×宽×高, L X W X H） |
仪器重量 Net Weight | 约80kg |
电源Power supply | AC220V±5，50~60Hz |
执行标准Carried Standard | GB/T230.2国家标准 GB/T 230.2 Chinese Standard JJG112检定规程 JJG112 Inspection Rule |
标准配件 附件 Standard Accessories | 金刚石洛氏压头，直经1.5875mm硬质合金球压头，大平试台、中平试台、“V”型试台，硬度块，RS-232通讯线，电源线 Diamond Rockwell Indenter, Diameter 1.5875mm Hard Alloy Steel Ball Indenter, Large Testing Table , Medium Testing TableV-shaped Testing table, HR30NHR30T Hardness Blocks, RS-232 Interface, Power Cable, etc. |
