UV-VIS
- 型号：MCS 621
- 产地：德国
- 供应商：科健企业公司
- 供应商报价：电议
- 标签：UV-VIS,供应UV-VIS,科健企业公司
产品库
型号 MCS621 UV-VIS
| Spectrometer | CLH 600 | CLH 606 F | CLH 606 A | CLD 600 | BLX600 | BLX606 |
| MCS 621 UV-VIS | 380-720 nm | 340-720 nm | 380-720 nm | 215-620nm | 240-720 nm | 260-720 nm |
CLH600,CLH606F, CLH 606 A, CLD 600, BLX 600, BLX 606是光源型号
规格
MCS 621 UV-VIS / CLD Specification
MCS 621 UV-VIS / CLD （215-720 nm）
| Spectrometer | Single beam diode array | |
| Polychromatic type | MMS | |
| Diode array | Hamamatsu S3904 | |
| Number of pixels | 256 | |
| Wavelength range | 215-720 nm | |
| Spec. wavelength range | 215-720 nm （Deuterium lamp） | |
| Wavelength resolution | 2.2 nm/pixel | |
| Wavelength accuracy | < 0.5 nm | |
| Wavelength reproducibility | < 0.05 nm | |
| Measuring range | 0 - 3 AU | |
| Accuracy | < 20 mAU | |
| Noise | < 0.1 mAU RMS （1s measuring time） | |
| Stray light | <0.2% at 340 nm （withNaNO2） | |
| Drift | < 0.5% /h | |
| Light sources | Deuterium lamp, 25 W | |
| Lifetime of the light sources | 1500 h | |
| Measuring rate | max. 50 measurements/s | |
| Interface spectrometer-PC | Ethernet | |
| Distance spectrometer-PC | < 100 m | |
| Casing | 19", 3 HE | |
