热卖A(E)0505S-2WDC-DC模块电源 热卖A(E)0505S-2WDC-DC模块电源

2W, Miniature SIP, Dual Output DC/DC Converters
F Features
l       Efficiency up to 88%
l       1000VDC /3000VDC Isolation
l       MTBF > 2,000,000 Hours
l       Low Cost
l       Input 5, 12, 15 and 24VDC
l       Output ±3.3, ±5, ±9, ±12, ±15and±24
l       Temperature Performance -40℃~ +85℃
l       UL 94V-0 Package Material
l       Internal SMD Construction
l       Industry Standard Pin out
Block Diagram   ABSOLUTE MAXIMUM RATINGS

Short-Circuit Protection	1Second
Lead Temperature 1.5mm from case for seconds	300℃
Internal Power Dissipation	450mW
Input Voltage Vin , A(E)05types	7V
Input Voltage Vin ,A(E)12 types	15V
Input Voltage Vin ,A(E)15 types	18V
Input Voltage Vin ,A(E) 24 types	28V

Model Selection Guide

Model Number	Input Voltage	Input Current		Output Voltage	Output Current	Efficiency
		Max Load	No Load			Max Load
	VDC	mA (typ)	mA(typ)	VDC	mA(max)	%(typ)
A(E)0503S-2W	5(4.5~5.5)	470	55	±3.3	±260	73
A(E)0505S-2W		520		±5	±200	77
A(E)0509S-2W		511		±9	±112	79
A(E)0512S-2W		499		±12	±83	80
A(E)0515S-2W		496		±15	±67	81
A(E)0524S-2W		492		±24	±42	82
A(E)1203S-2W	12(10.8~13.2)	193	22	±3.3	±260	74
A(E)1205S-2W		210		±5	±200	79
A(E)1209S-2W		210		±9	±112	80
A(E)1212S-2W		203		±12	±83	82
A(E)1215S-2W		204		±15	±67	82
A(E)1224S-2W		200		±24	±42	84
A(E)1503S-2W	15(13.5~16.5)	155	18	±3.3	±260	74
A(E)1505S-2W		168		±5	±200	79
A(E)1509S-2W		167		±9	±112	80
A(E)1512S-2W		163		±12	±83	82
A(E)1515S-2W		163		±15	±67	82
A(E)1524S-2W		160		±24	±42	84
A(E)2403S-2W	24(21.6~26.4)	97	15	±3.3	±260	73
A(E)2405S-2W		106		±5	±200	79
A(E)2409S-2W		103		±9	±112	81
A(E)2412S-2W		101		±12	±83	82
A(E)2415S-2W		100		±15	±67	84
A(E)2424S-2W		96		±24	±42	88

Input Specifications

Parameter	Model	Min	Typ	Max	Unit
Input Voltage	5	4.5	5	5.5	VDC
	12	10.8	12	13.2
	15	13.5	15	16.5
	24	21.6	24	26.4
Reverse Polarity Input Current	All Models			0.3	A
Input Filter		Internal Capacitor

Output specifications

Parameter	Conditions	Min	Typ	Max	Unit
Output Voltage Accuracy		﹎	±1.0	±3.0	%
Output Voltage Balance	Dual Output Balanced Loads	﹎	±0.1	±1.0	%
Line Regulation	For  Vin Change of 1%	﹎	±1.2	±1.5	%
Load Regulation	Io＝20% to		8	10	%
Ripple﹠Noise(20MHz)	5~15V Output	﹎	50	75	mV P-P
	18~24			150
Ripple﹠Noise(20MHz)	Over Line , Load﹠Temp	﹎	﹎	200	mV P-P
Ripple﹠Noise(20MHz)		﹎	﹎	10	mV RMS
Over Load		120	﹎	﹎	%
Temperature Coefficient		﹎	±0.01	±0.02	%/℃
Output Short Circuit	1 Second


General Specifications

Parameter	Conditions	Min	Min	Typ	Max	Unit
		A Series	E Series
Isolation Voltage Rated	60 Seconds	1000	3000	﹎	﹎	VDC
Isolation Voltage Test	Flash  Tested  for 1 Second	1000	3000	﹎	﹎	VAC
Isolation Resistance	500VDC	1000	1000	﹎	﹎	MΩ
Isolation Capacitance	100KHz,1V	﹎		60	100	PF
Switching Frequency		50	50	100	120	KHz
MTBF	MIL-HDBK-217F@25℃,Ground benign	2000	2000	﹎	﹎	K Hours


Environmental Specifications

Parameter	Conditions	Min	Typ.	Max	Unit
Operating Temperature	Ambient	-40	﹎	＋85	℃
Operating Temperature	Case	-40	﹎	＋90	℃
Storage Temperature	﹎	-40	﹎	＋125	℃
Humidity	﹎	﹎	﹎	95	%
Cooling	Free-Air convection

MECHANICAL DIMENSIONS            TUBE OUTLINE DIMENSIONS




A Series                                       E Series
RECOMMENDED FOOTPRINT DETAIS         RECOMMENDED FOOTPRINT DETAIS


  Pin Connection                   Physical Characteristics
                                             Case Size      : 19.6×7.0×10mm

Pin	A Series	E Series
1	+Vin	+ Vin
2	-Vin	-Vin
4	-Vout	No Pin
5	COM	-Vout
6	+Vout	COM
7	No Pin	+Vout

                           0.77×0.26×0.394 inches
           Case Material   :  Non-Conductive Black Plastic
             Weight        :   2.7g ± 0.2g
