124-43柔性版，导电油墨和涂料

124-43柔性版，导电油墨和涂料

说明：124-43是一种碳填充水性，低V.O.C.，导电油墨和涂料，

适用于柔版印刷。本产品具有与卡普顿、玻璃和

其他各种表面。与传统的导电材料不同，这种产品非常耐弯曲

还有折痕。124-43的一些应用包括但不限于医用电极、聚合物

厚膜电路，薄膜开关和静电消除。

典型固化特性：

粘度（cps.）1100

抗皱性佳

片材电阻率，100°C固化（Ω/sq./mil.值）20

可焊性编号

水解稳定性优异

有效温度范围（℃）-55至+140

热稳定性（摄氏度）达到175

V.O.C.克/升139

建议处理和固化：在使用混合料之前，将填料重新悬浮。124-43在

适用于柔版印刷的粘度。本品可用蒸馏水进一步稀释。

通过在100°C下固化10分钟，可在多种基材上获得性能。良好的性能包括

也可通过在50°C至175°C的温度下固化在多种基材上获得。用户

建议通过实验确定Z适合个人应用的温度和时间。

贮存期：21°C下保存6个月。不允许冷冻。

124-43柔性版，导电油墨和涂料

124-43
CARBON FILLED, WATERBORNE, LOW V.O.C., FLEXOGRAPHIC, CONDUCTIVE
INK & COATING
DESCRIPTION: 124-43 is a carbon filled waterborne, low V.O.C., electrically conductive ink and coating,
suitable for application by flexographic methods. This product features adhesion to Kapton, glass, and a
variety of other surfaces. Unlike conventional conductive materials, this product is very resistant to flexing
and creasing. Some applications for 124-43 include, but are not limited to, medical electrodes, polymer
thick film circuitry, and membrane switches and static elimination.
TYPICAL CURED PROPERTIES:
Viscosity (cps.) 1100
 Crease Resistance Excellent
 Sheet Resistivity, 100°C cure (Ω/sq./mil. max.) 20
 Solderable No
 Hydrolytic Stability Excellent
 Useful Temperature Range (°C) -55 to +140
 Thermal Stability (°C) Good to 175
V.O.C.'s grams/liter 139
SUGGESTED HANDLING & CURING: Before using mix well to re-suspend filler. 124-43 is supplied at a
viscosity suitable for flexographic printing. This product can be thinned further with distilled water. Best
properties are obtained on a variety of substrates by curing for 10 minutes at 100°C. Good properties are
also obtained on a variety of substrates by curing at temperatures ranging from 50°C to 175°C. End user
is advised to experimentally determine temperature and time best suited for individual applications.
STORAGE: Shelf Life: 6 months at 21°C. DO NOT ALLOW TO FREEZE.
