TEN 20-4810 TEN 20-2423 TRACO电源模块
- 型号：TEN 20-4810
- 产地：瑞士
- 供应商：西安云特电子技术有限公司
- 供应商报价：面议
- 标签：TEN 20-2423 TRACO电源模块,-1,西安云特电子技术有限公司
产品库
| 品牌 | 自营品牌 | 规格 | TEN 20-4823 |
|---|---|---|---|
| 供货周期 | 一个月 | 主要用途 | 供电 |
High Performance 20 to 60W
DC / DC Converter Modules High Performance 20 to 60W
The TEN series is an extensive range of high performance DC/DC converters offering excellent specifications and very high power density in shielded metal packages.
All models are available with wide 2:1 or ultra-wide 4:1 input ranges .
The TEN series models offer an extended operating temperature range of –40 to +85°C and provide an internal EMI-filter to meet EN/UL 55022, class A.
Product Series | Output Power | Input Voltage Range [VDC] | Output Voltage [VDC] | Package Style / Features | |
|---|---|---|---|---|---|
|
| 20W | 9-18, 18-36, 36-75 | 3.3, 5, 12, 15, ±12, ±15 | 1" x 1", |
|
| 20W | 9-36, 18-75 | 3.3, 5, 12, 15, ±12, ±15 | 1" x 1", |
|
| 20W | 9-18, 18-36, 36-75 | 3.3, 5, 12, 15, ±12, ±15 | 1" x 2", |
|
| 20W | 9-36, 18-75 | 3.3, 5, 12, 15, ±5, ±12, ±15 | 1" x 2", |
NEW |
| 20W | 9-36, 18-75, 43-160 | 3.3, 5, 12, 15, ±12, ±15 | 1" x 2", |
|
| 25W/30W | 9-18, 18-36, 36-75 | 3.3, 5, 12, 15, ±12, ±15 | 1.6" x 2", |
|
| 25W/30W | 10-40, 18-75 | 3.3, 5, 12, 15, ±12, ±15 | 1.6" x 2", |
NEW |
| 30W | 9-18, 18-36, 36-75 | 3.3, 5, 12, 15, 24, ±12, ±15 | 1" x 1", |
NEW |
| 30W | 9-36, 18-75 | 3.3, 5, 12, 15, 24, ±12, ±15 | 1" x 1", |
|
| 30W | 9-18, 18-36, 36-75 | 1.5, 2.5, 3.3, 5.1, 12, 15, ±5, ±12, ±15 | 1" x 2", |
|
| 30W | 10-40, 18-75 | 1.8, 2.5, 3.3, 5, 12, 15, ±12, ±15 | 1.6" x 2" |
|
| 30W | 9-36, 18-75 | 1.8, 2.5, 3.3, 5, 12, 15, ±12, ±15 | 1" x 2", |
|
| 40 W | 9-18, 18-36, 36-75 | 3.3, 5, 12, 15, ±12, ±15 | 2" x 1" |
NEW |
| 40 W | 9-36, 18-75 | 3.3, 5, 12, 15, ±12, ±15 | 2" x 1" |
NEW |
| 40 W | 9-36, 18-75, 43-160 | 3.3, 5, 12, 15, 24, ±12, ±15 | 1" x 2", |
|
| 40W | 9-18, 18-36, 36-75 | 3.3, 5, 12, 15 , 3.3/5, ±12, ±15, 3.3/±12, 3.3/±15, 5/±12, 5/±15 | 2" x 2", |
|
| 40W | 9-36, 18-75 | 3.3, 5, 12, 15, ±12, ±15 | 2" x 2", |
|
| 60W | 18-36, 36-75 | 3.3, 5, 12, 15, 24 | 2" x 2", |
TEN20系列
The TEN 20 series of DC/DC converters , comprising 18 different models,
has been designed for a wide range of applications including
communications, industrial systems and battery powered equipments. Full
SMD-design with use of ceramic chip capacitors guarantees a high reliability
and a long lifetime. Other features of this converters are internal filter to
meet EN 55022, class A and FCC, level A and an extended temperature
range of -40°C to +85°C.
TEN 20-1210
TEN 20-1211
TEN 20-1212
TEN 20-1213
TEN 20-1222
TEN 20-1223
TEN 20-2410
TEN 20-2410
TEN 20-2412
TEN 20-2413
TEN 20-2422
TEN 20-2423
TEN 20-4810
TEN 20-4811
TEN 20-4812
TEN 20-4813
TEN 20-4822
TEN 20-4823
TEN20WI系列
The TEN 20WI series is a family of high performance 20W DC/DC converter modules featuring ultra wide 4:1 input voltage ranges in a compact 2“ x 1.6“ low profile package with industry-standard footprint. A very high efficiency allows an operating temperature range of –40°C to 85°C. A built-in EMI input filter complies with EN 55022, class A without external components. Further standard features include remote On/Off, output voltage trimming, over voltage protection and short-circuit protection.
Typical applications for these converters are battery operated equipment and distributed power architectures in communication and industrial electronics, everywhere where isolated, tightly regulated voltages are required.
TEN 20-2411WI
TEN 20-2412WI
TEN 20-2413WI
TEN 20-2421WI
TEN 20-2422WI
TEN 20-2423WI
TEN 20-4811WI
TEN 20-4812WI
TEN 20-4813WI
TEN 20-4821WI
TEN 20-4822WI
TEN 20-4823WI
TEN20WIN系列
The TEN 20WIN series is a family of high performance 20W DC/DC converter
modules featuring ultra wide 4:1 input voltage ranges in a ultra compact 2“ x 1“
low profile package with industry-standard footprint. A very high efficiency allows
an operating temperature range of –40°C to 85°C. Further standard features
include remote On/Off, output voltage trimming, over voltage protection and shortcircuit
protection.
Typical applications for these converters are battery operated equipment and distributed
power architectures in communication and industrial electronics, everywhere
where isolated, tightly regulated voltages are required.
TEN 20-2410WIN
TEN 20-2411WIN
TEN 20-2412WIN
TEN 20-2413WIN
TEN 20-2421WIN
TEN 20-2422WIN
TEN 20-2423WIN
TEN 20-4810WIN
TEN 20-4811WIN
TEN 20-4812WIN
TEN 20-4813WIN
TEN 20-4821WIN
TEN 20-4822WIN
TEN 20-4823WIN
THN20系列
The THN-20 series is the latest generation of high performance dc-dc converter
modules with highest power density. The product achieves 20W output power while
it comes in a metal case with dimensions of only 1.0”x 1.0”x 0.4”.
All models have an wide 2:1 input voltage range and precisely regulated output
voltages, even under no load conditions. Highest efficiency of up to 90% makes this
product very reliable and applicable in temperature ranges of up to 75°C or 85°C
with optional mounted heat sink. Together with low input current characteristics at
minimal load and remote On/Off control these converters are the ideal solution for
battery-operated systems. Typical applications are in equipments, instrumentation,
distributed power architectures in communication and industrial electronics
and everywhere where space on the PCB is critical.
THN 20-1210
THN 20-1211
THN 20-1212
THN 20-1213
THN 20-1222
THN 20-1223
THN 20-2410
THN 20-2411
THN 20-2412
THN 20-2413
THN 20-2422
THN 20-2423
THN 20-4810
THN 20-4811
THN 20-4812
THN 20-4813
THN 20-4822
THN 20-4823
TEN20WIR系列
TEN20WIR系列是一个高性能20瓦的直流/直流转换器
模块具有超宽输入电压范围4:1 2 " x 1”包
符合行业标准的要求。输入电压160 v,优良的电磁兼容特性
和en15038批准使该产品的Z佳选择,很多
高要求应用于铁路和交通系统。进一步的标准
功能包括远程开启/关闭、过压保护,在电压停摆
和短路保护。低输入电流特性以Z小负荷使
这些转换器也为电池供电系统的理想的解决方案。典型的应用程序
在无线网络、电信/数据通信,工业控制系统和吗
测量设备
Order code | Input voltage range | Output voltage | Output current max. | Efficiency typ. | |||
TEN 20-2410WIR | 3.3 VDC | 4500 mA | 85 % | ||||
TEN 20-2411WIR | 5.0 VDC | 4000 mA | 88 % | ||||
TEN 20-2412WIR | 9 – 36 VDC | 12 VDC | 1670 mA | 89 % | |||
TEN 20-2413WIR | (24 VDC nominal) | 15 VDC | 1330 mA | 88 % | |||
TEN 20-2422WIR | ±12 VDC | ±833 mA | 88 % | ||||
TEN 20-2423WIR | ±15 VDC | ±667 mA | 89 % | ||||
TEN 20-4810WIR | 3.3 VDC | 4500 mA | 85 % | ||||
TEN 20-4811WIR | 5.0 VDC | 4000 mA | 88 % | ||||
TEN 20-4812WIR | 18 – 75 VDC | 12 VDC | 1670 mA | 89 % | |||
TEN 20-4813WIR | (48 VDC nominal) | 15 VDC | 1330 mA | 89 % | |||
TEN 20-4822WIR | ±12 VDC | ±833 mA | 88 % | ||||
TEN 20-4823WIR | ±15 VDC | ±667 mA | 89 % | ||||
TEN 20-7210WIR | 3.3 VDC | 4500 mA | 85 % | ||||
TEN 20-7211WIR | 5.0 VDC | 4000 mA | 87 % | ||||
TEN 20-7212WIR | 43 – 160 VDC | 12 VDC | 1670 mA | 88 % | |||
TEN 20-7213WIR | (110 VDC nominal) | 15 VDC | 1330 mA | 89 % | |||
TEN 20-7222WIR | ±12 VDC | ±833 mA | 88 % | ||||
TEN 20-7223WIR | ±15 VDC | ±667 mA | 89 % | ||||
TEN25系列
The TEN 25 series is a range of isolated DC/DC converters with high power density
in a 51x41x9.5mm shielded metal case. All 18 models have a wide 2:1 input voltage
range. The very high efficiency allows a safe operating temperature range of
–40°C to +85°C. Other features are internal EMI-filter to meet EN55022, class A
and remote On/Off. Typical applications for these converter modules are industrial
electronics, communication systems, battery operated equipment and distributed
power systems.
TEN 25-1210
TEN 25-1211
TEN 25-1212
TEN 25-1213
TEN 25-1222
TEN 25-1223
TEN 25-2410
TEN 25-2411
TEN 25-2412
TEN 25-2413
TEN 25-2422
TEN 25-2423
TEN 25-4810
TEN 25-4811
TEN 25-4812
TEN 25-4813
TEN 25-4822
TEN 25-4823
TEN25WI系列
The TEN 25WI series is a family of high performance dc-dc converter modules up to 30 Watt featuring ultra wide 4:1 input voltage ranges in a compact low profile case with industry standard footprint. Standard features include remote On/Off, output voltage trimming, over voltage protection, under voltage lockout, over temperature and short circuit protection.
An other features is the internal EMI-filter to meet EN 55022, class A. Typical applications for these converter modules are industrial electronics, communication systems, battery operated equipment and distributed power systems.
TEN 25-2410WI
TEN 25-2411WI
TEN 25-2412WI
TEN 25-2413WI
TEN 25-2422WI
TEN 25-2423WI
TEN 25-4810WI
TEN 25-4811WI
TEN 25-4812WI
TEN 25-4813WI
TEN 25-4822WI
TEN 25-4823WI
TEN30系列
The TEN-30 series is the latest generation of high performance dc-dc converter modules setting a new standard concerning power density. This product with 30W comes in an encapsulated, shielded metal package with a footprint of only
1.0” x 2.0”. All models have wide 2:1 input voltage range and precisely regulated, isolated output voltages. Advanced circuit topology provides high efficiency up to 91% which allows an industrial operating temperature range of –40°C to +85°C (with derating).
Further features include remote On/Off, trimmable output, under-voltage lockout and overtemperature protection. Typical applications for these converters are equipment, instrumentation, distributed power architectures in communication and industrial electronics and everywhere where space on the PCB is critical.
TEN 30-1207
TEN 30-1209
TEN 30-1210
TEN 30-1211
TEN 30-1212
TEN 30-1213
TEN 30-1221
TEN 30-1222
TEN 30-1223
TEN 30-2407
TEN 30-2409
TEN 30-2410
TEN 30-2411
TEN 30-2412
TEN 30-2413
TEN 30-2421
TEN 30-2422
TEN 30-2423
TEN 30-4807
TEN 30-4809
TEN 30-4810
TEN 30-4811
TEN 30-4812
TEN 30-4813
TEN 30-4821
TEN 30-4822
TEN 30-4823
TE30WI系列
The TEN 30WI series is a family of high performance 30W dc-dc converters featuring
ultra wide 4:1 input voltage ranges in a compact low profile package with
industry-standard footprint. A very high efficiency allows operating temperatures
up to 85°C. A built-in filter for both input and output minimizes the need for external
filtering. Further standard features include remote On/Off, output voltage trimming,
over voltage protection, under voltage lockout and short circuit protection.
Typical applications for these products are battery operated equipment and distributed
power architectures in communication and industrial electronics, everywhere
where isolated, tightly regulated voltages are required and space is limited on the
PCB.
Order
TEN 30-2408WI
TEN30-2409WI
TEN30-2410WI
TEN30-2411WI
TEN30-2412WI
TEN30-2413WI
TEN30-2422WI
TEN30-2423WI
TEN30-4808WI
TEN30-4809WI
TEN30-4810WI
TEN30-4811WI
TEN30-4812WI
TEN30-4813WI
TEN30-4822WI
TEN30-4823WI
TEN30WIN系列
The TEN 30WIN series is a family of high performance 30W dc-dc converter
modules featuring ultra wide 4:1 input voltage ranges in a compact low profile case with industry-standard footprint. Standard features include remote On/Off, output voltage trimming, over voltage protection, under voltage lockout, over temperature and short circuit protection.
Typical applications for these products are battery operated equipment and
distributed power architectures in communication and industrial electronics, everywhere where isolated, tightly regulated voltages are required and space is limited on the PCB.
TEN 30-2407WIN
TEN 30-2409WIN
TEN 30-2410WIN
TEN 30-2411WIN
TEN 30-2412WIN
TEN 30-2413WIN
TEN 30-2421WIN
TEN 30-2422WIN
TEN 30-2423WIN
TEN 30-2433WIN
TEN 30-2434WIN
TEN 30-2431WIN
TEN 30-2432WIN
TEN 30-4807WIN
TEN 30-4809WIN
TEN 30-4810WIN
TEN 30-4811WIN
TEN 30-4812WIN
TEN 30-4813WIN
TEN 30-4821WIN
TEN 30-4822WIN
TEN 30-4823WIN
TEN 30-4833WIN
TEN 30-4834WIN
TEN 30-4831WIN
TEN 30-4832WIN
THN30WI系列
The THN-30WI series is the latest generation of high performance DC/DC converter
modules with highest power density. The product achieves 30W output power while
it comes in a metal case with dimensions of only 1.0”x 1.0”x 0.4”.
All models have an ultra wide 4:1 input voltage range and precisely regulated
output voltages, even under no load conditions. Highest efficiency across full load
range makes this product very reliable and applicable in temperature ranges of up
to 85°C. With a low input current at minimal load and remote On/Off control these
converters are the ideal solution for battery-operated systems. Typical applications
are in equipments, instrumentation, distributed power architectures in communication
and industrial electronics and everywhere where space on the PCB is
critical.
Order code | Input voltage range | Output voltage | Output current max. | Efficiency typ. | |||
THN 30-2410WI | 3.3 VDC | 7000 mA | 86 % | ||||
THN 30-2411WI | 5.0 VDC | 6000 mA | 89 % | ||||
THN 30-2412WI | 12 VDC | 2500 mA | 89 % | ||||
THN 30-2413WI | 9 – 36 VDC | 15 VDC | 2000 mA | 89 % | |||
THN 30-2415WI | (24 VDC nominal) | 24 VDC | 1250 mA | 89 % | |||
THN 30-2422WI | ±12 VDC | ±1250 mA | 89 % | ||||
THN 30-2423WI | ±15 VDC | ±1000 mA | 91 % | ||||
THN 30-4810WI | 3.3 VDC | 7000 mA | 87 % | ||||
THN 30-4811WI | 5.0 VDC | 6000 mA | 90 % | ||||
THN 30-4812WI | 18 – 75 VDC | 12 VDC | 2500 mA | 90 % | |||
THN 30-4813WI | (48 VDC nominal) | 15 VDC | 2000 mA | 91 % | |||
THN 30-4815WI | 24 VDC | 1250 mA | 91 % | ||||
THN 30-4822WI | ±12 VDC | ±1250 mA | 91 % | ||||
THN 30-4823WI | ±15 VDC | ±1000 mA | 92 % | ||||
THN30系列
The THN-30 series is the latest generation of high performance DC/DC converter
modules with highest power density. The product achieves 30W output power while
it comes in a metal case with dimensions of only 1.0”x 1.0”x 0.4”.
All models have an wide 2:1 input voltage range and precisely regulated output
voltages, even under no load conditions. Highest efficiency across load range makes
this product very reliable and applicable in temperature ranges of up to 85°C. With
a low input current at no load and remote On/Off control these converters are
the ideal solution for battery-operated systems. Typical applications are in
equipments, instrumentation, distributed power architectures in communica
tion and industrial electronics and everywhere where space on the PCB is critical.
Order code Input voltage range Output voltage Output current max. Efficiency typ.
THN 30-1210 3.3 VDC 7000 mA 86 %
THN 30-1211 5.0 VDC 6000 mA 89 %
THN 30-1212
9 – 18 VDC
12 VDC 2500 mA 89 %
THN 30-1213
(12 VDC nominal)
15 VDC 2000 mA 89 %
THN 30-1215 24 VDC 1250 mA 89 %
THN 30-1222 ±12 VDC ±1250 mA 89 %
THN 30-1223 ±15 VDC ±1000 mA 90 %
THN 30-2410 3.3 VDC 7000 mA 87 %
THN 30-2411 5.0 VDC 6000 mA 90 %
THN 30-2412
18 – 36 VDC
12 VDC 2500 mA 91 %
THN 30-2413
(24 VDC nominal)
15 VDC 2000 mA 91 %
THN 30-2415 24 VDC 1250 mA 91 %
THN 30-2422 ±12 VDC ±1250 mA 91 %
THN 30-2423 ±15 VDC ±1000 mA 91 %
THN 30-4810 3.3 VDC 7000 mA 87 %
THN 30-4811 5.0 VDC 6000 mA 89 %
THN 30-4812
36 – 75 VDC
12 VDC 2500 mA 90 %
THN 30-4813
(48 VDC nominal)
15 VDC 2000 mA 91 %
THN 30-4815 24 VDC 1250 mA 91 %
THN 30-4822 ±12 VDC ±1250 mA 91 %
THN 30-4823 ±15 VDC ±1000 mA 92 %
TEN40系列
The TEN 40 series is a family of high performance 40W dc-dc converter modules
featuring 30 standard models with wide 2:1 input voltage ranges in a compact low
profile case with industry-standard footprint. A very high efficiency allows an operating
temperature range of –40°C to 85°C. Built-in filters for both input and output
minimizes the need for external filtering. Further standard features include remote
On/Off, output voltage trimming, over voltage protection, under voltage lockout and
short circuit protection.
Typical applications for these products are battery operated equipment and distributed
power architectures in communication and industrial electronics, everywhere where
isolated, tightly regulated voltages are required and space is limited on the PCB.
TEN 40-1210
TEN 40-1211
TEN 40-1212
TEN 40-1220
TEN 40-1222
TEN 40-1223
TEN 40-1233
TEN 40-1234
TEN 40-1231
TEN 40-1232
TEN 40-2410
TEN 40-2411
TEN 40-2412
TEN 40-2420
TEN 40-2422
TEN 40-2423
TEN 40-2433
TEN 40-2434
TEN 40-2431
TEN 40-2432
TEN 40-4810
TEN 40-4811
TEN 40-4812
TEN 40-4820
TEN 40-4822
TEN 40-4823
TEN 40-4833
TEN 40-4834
TEN 40-4831
TEN 40-4832
TEN40WI系列
The TEN 40WI series is a family of high performance 40W dc-dc converter modules
featuring ultra wide 4:1 input voltage ranges in a compact low profile case with
industry-standard footprint. A very high efficiency allows an operating temperature
range of –40°C to 85°C. Further standard features include remote On/Off, output
voltage trimming, over voltage protection, under voltage lockout, over temperature
and short circuit protection.
Typical applications for these products are battery operated equipment and distributed
power architectures in communication and industrial electronics, everywhere
where isolated, tightly regulated voltages are required and space is limited on the
PCB.
Page
TEN 40-2410WI
TEN 40-2411WI
TEN 40-2412WI
TEN 40-2413WI
TEN 40-2422WI
TEN 40-2423WI
TEN 40-4810WI
TEN 40-4811WI
TEN 40-4812WI
TEN 40-4813WI
TEN 40-4822WI
TEN 40-4823WI
The TEN 40N Series is a new range of isolated high performance dc-dc converter modules. Due to the very high efficiency of up to 92% these 40W converters come with a footprint of only 1.0” x 2.0”. The 15 models have a wide 2:1 input voltage range and a tight output voltage regulation. The output voltage is adjustable by external resistor. Remote On/Off and protection against overpower and overvoltage are standard features of these converters.
Typical applications are in equipment, instrumentation, distributed power architectures in communication and industrial electronics and everywhere where space on the PCB is critical.
DC/DC Converters
TEN 40N Series, 40 Watt
Features
◆ Highest power density:
40 W in 1” x 2” x 0.4” package
◆ Excellent efficiency up to 92 %
◆ Output voltage adjustable
◆ Remote On/Off
◆ Short circuit protection
◆ Over voltage protection
◆ I/O isolation 1500 VDC
◆ Input filter meets EN 55022, class A and FCC, level A without external components
◆ Operating temperature range
–40°C to +71°C
◆ Fully RoHS compliant
◆ 3-year product warranty
The TEN 40N Series is a new range of isolated high performance dc-dc converter modules. Due to the very high efficiency of up to 92% these 40W converters come with a footprint of only 1.0” x 2.0”. The 15 models have a wide 2:1 input voltage range and a tight output voltage regulation. The output voltage is adjustable by external resistor. Remote On/Off and protection against overpower and overvoltage are standard features of these converters.
Typical applications are in equipment, instrumentation, distributed power architectures in communication and industrial electronics and everywhere where space on the PCB is critical.
TEN 40-1210N | 3.3 VDC | 8‘000 mA | 89 % | ||||
TEN 40-1211N | 5.0 VDC | 8’000 mA | 89 % | ||||
TEN 40-1212N | 9 – 18 VDC | 12 VDC | 3‘333 mA | 89 % | |||
TEN 40-1213N | (nominal 12 VDC) | 15 VDC | 2‘666 mA | 90 % | |||
TEN 40-1222N | ±12 VDC | ±1’666 mA | 88 % | ||||
TEN 40-1223N | ±15 VDC | ±1‘333 mA | 88 % | ||||
TEN 40-2410N | 3.3 VDC | 8‘000 mA | 90 % | ||||
TEN 40-2411N | 5.0 VDC | 8’000 mA | 91 % | ||||
TEN 40-2412N | 18 – 36 VDC | 12 VDC | 3‘333 mA | 91 % | |||
TEN 40-2413N | (nominal 24 VDC) | 15 VDC | 2‘666 mA | 91 % | |||
TEN 40-2422N | ±12 VDC | ±1’666 mA | 89 % | ||||
TEN 40-2423N | ±15 VDC | ±1‘333 mA | 89 % | ||||
TEN 40-4810N | 3.3 VDC | 8‘000 mA | 90 % | ||||
TEN 40-4811N | 5.0 VDC | 8’000 mA | 91 % | ||||
TEN 40-4812N | 36 – 75 VDC | 12 VDC | 3‘333 mA | 92 % | |||
TEN 40-4813N | (nominal 48 VDC) | 15 VDC | 2‘666 mA | 92 % | |||
TEN 40-4822N | ±12 VDC | 1’666 mA | 89 % | ||||
TEN 40-4823N | ±15 VDC | 1‘333 mA | 89 % | ||||
TEN50系列
The TEN 50 Series is a range of isolated �����p����������c-������������high erformance dc-dcconverter modules. Due to the very high efficiency of upto 92% and the use of highest reliable components these 50 W converters come with a footprint of only 1.0” x 2.0”. The 12 models have a wide 2:1 input voltage range and a tight output voltage regulation. They do not need a minimumload and a offer a high efficiency also at low load conditions. The output voltage is adjustable by external resistor. Remote On/Off and protection against overload and short circuit are standard features of these converters.
Typical applications are in equipment, instrumentation, distributed power architectures in communication and industrial electronics and everywhere where space on the PCB is critical.
Order code | Input voltage range | Output voltage | Output current max. | Efficiency | |||
TEN 50-1210 | 3.3 VDC | 10‘000 mA | 89 % | ||||
TEN 50-1211 | 9 – 18 VDC | 5.0 VDC | 10’000 mA | 90 % | |||
TEN 50-1212 | (nominal 12 VDC) | 12 VDC | 4‘167 mA | 91 % | |||
TEN 50-1213 | 15 VDC | 3‘333 mA | 91 % | ||||
TEN 50-2410 | 3.3 VDC | 10‘000 mA | 89 % | ||||
TEN 50-2411 | 18 – 36 VDC | 5.0 VDC | 10’000 mA | 92 % | |||
TEN 50-2412 | (nominal 24 VDC) | 12 VDC | 4‘167 mA | 92 % | |||
TEN 50-2413 | 15 VDC | 3‘333 mA | 92 % | ||||
TEN 50-4810 | 3.3 VDC | 10‘000 mA | 89 % | ||||
TEN 50-4811 | 36 – 75 VDC | 5.0 VDC | 10’000 mA | 92 % | |||
TEN 50-4812 | (nominal 48 VDC) | 12 VDC | 4‘167 mA | 92 % | |||
TEN 50-4813 | 15 VDC | 3‘333 mA | 92 % | ||||
TEN60系列
The TEN 60 series is a family of high performance 60W dc-dc converter modules with wide 2:1 input voltage ranges in a compact low profile case with industry-standard footprint. A very high efficiency allows an operating temperature range of –40°C to 85°C. Built-in filters for both input and output minimizes the need for external filtering. Further standard features include remote On/Off, output voltage trimming, over voltage protection, under voltage lockout and short circuit protection.
Typical applications for these products are battery operated equipment and distributed power architectures in communication and industrial electronics, everywhere where isolated, tightly regulated voltages are required and space is limited on the PCB.
TEN 60-2410
TEN60-2411
TEN60-2412
TEN60-2413
TEN60-4810
TEN60-4811
TEN60-4812
TEN60-4813
