XBeeTM ZigBee OEM RF 模块

Platform

XBee® ZB

XBee-PRO® ZB

Performance

RF Data Rate

250 Kbps

Indoor/Urban Range

133 ft (40 m)

300 ft. (90 m) / Int‘l 200 ft (60 m)

Outdoor/RF Line-of-Sight Range

400 ft (120 m)

2 miles (3200 m)/ Int’l 5000 ft (1500 m)

Transmit Power

1.25 mW (+1 dBm) / 2 mW (+3 dBm) boost mode

63 mW (+18 dBm) / Int’l 10 mW (+10 dBm)

Receiver Sensitivity (1% PER)

-96 dBm in boost mode

-102 dBm

Features

Adjustable Power

Yes

Serial Data Interface

3.3V CMOS UART

Configuration Method

API or AT commands, local or over-the-air

Frequency Band

2.4 GHz

Interference Immunity

DSSS (Direct Sequence Spread Spectrum)

Serial Data Rate

1200 bps - 1 Mbps

ADC Inputs

(4) 10-bit ADC inputs

Digital I/O

10

Antenna Options

Chip, Wire Whip, U.FL RPSMA

PCB Embedded Antenna, Wire Whip, U.FL, RPSMA

Programmability

No

Yes

Networking & Security

Encryption

128-bit AES

Reliable Packet Delivery

Retries/Acknowledgments

IDs and Channels

PAN ID, 64-bit IEEE MAC, 16 channels

PAN ID, 64-bit IEEE MAC, 15 channels

Power Requirements

Supply Voltage

2.1 - 3.6VDC

2.7 - 3.6VDC

Transmit Current

35 mA / 45 mA boost mode @ 3.3VDC

205 mA, up to 220 mA with programmable variant

Receive Current

38 mA / 40 mA boost mode @ 3.3VDC

47 mA, up to 62 mA with programmable variant

Power-Down Current

<1 uA @ 25º C

3.5 uA, 4 uA @ 25º C with programmable variant

Regulatory Approvals

FCC (USA)

Yes

IC (Canada)

Yes

ETSI (Europe)

Yes

C-TICK (Australia)

Yes

TELEC (Japan)

Yes

Yes (int’l unit only)
