BURKERT控制器566001上海一级代理
- 产地：德国
- 供应商：宝德气动（上海）有限公司
- 供应商报价：面议
- 标签：BURKERT控制器566001上海一级代理,-1,宝德气动（上海）有限公司
产品库
| 品牌 | burkert/德国宝德 |
|---|
BURKERT现货库存：
079206K 0127-T-01,5-CC-TZ-UNFB-024/UC-03
079221H 0124-E-04,0-FF-PD-GM82-230/50-05
079223B 0124-B-03,0-FF-PD-GM82-230/50-08
079248U 0355-C-04,0-EF-VA-NM82-024/DC-12
079249V 0301-C-01,0-BB-PA-FK01-230/56-02
079264L F282-0-32,0-FF-VA-GM87-000/00-00
079264L F282-0-32,0-FF-VA-GM87-000/00-00
BURKERT控制器566001是一种微处理器传送器/控制器，用于直接连接提供原始信号的传感器，例如 pH 值、O.R.P.、电导率以及通过脉冲检测得出的流量。这种设备非常适合测量值的检测和调节以及相应的计量任务，例如，可被应用于水处理设备（比如锅炉、冷却塔和循环渗透系统）以及食品与制药设备中的各种用途。硬件和软件的模块性，提供了较高的灵活性，可根据用途结合相关的价格/功率关系对产品进行调整。高度成熟的电子设备和高度现代化的控制与调节算法，确保了Z佳的过程控制，在操作员干预Z少的情况下，能够随时确保Z优的质量。
BURKERT控制器566001特点：
可直接连接大多数流量传感器、pH 值/O.R.P.及电导率传感器
简单、直观的操作员界面，带有大型图形显示器和可调节的背景照明装置（4 个用户定义的视图）
可扩展的基础型传送器/控制器硬件（Z多 6 个可自由分配的插槽）
通过可选软件进行功能扩展
BURKERT控制器566001技术参数：
Mounting | Panel-mounted (standardized 1/4 DIN housing for 92 x 92 mm cutout) |
| Wall-mounted (with mounting plate) |
Materials |
|
Seal / Screws | Silicone / Stainless steel 316 |
Support plate for terminals | Stainless steel 304 |
Terminal blocks | PBT, contact in gold-plated copper alloy |
Display / Front panel and keys | PC / Silicone |
Housing |
|
Panel-mounted | PPO (incl. fastening element) |
Wall-mounted | PA66 (incl. fastening plate, cable gland, protecting cover (display), |
| protecting cap (free terminal place), stiffener hinge) |
Protective cap (110...240 V AC sup- |
|
plied wall-mounted version) | Stainless steel 304 |
Cover screws (wall-mounted version) | PVC |
Display | LC graphic display, light blue backlighted; 128 x 168 pixels |
| resolution; German, English, French languages |
Keypad | 4 soft keys [F1] [F2] [F3] [F4] for dynamic functions |
| 1 central navigation key with [é] [ê] [è] [ç] assignments |
Data logger | up to 16 values |
Sensor monitor | Direct display and verification of measured sensor values |
Clock | Real-time clock with date |
Board slots | 6 |
Electrical connection | Terminal blocks |
Recommended cable | Cable with max. operating temperature of min. 90°C |
Solid H05(07) V-U | 0.2...1.5 mm2, shielded cable |
Flexible H05(07) V-K | 0.2...1.5 mm2, shielded cable |
With wire end ferrule | 0.2...1.5 mm2, shielded cable |
With plastic collar ferrule | 0.2...1.5 mm2, shielded cable |
