glyclotech31-010 Glycotech 细胞流体剪切应力培养流动小室

产品信息
品牌 其他品牌 供货周期 现货





Parallel Plate Flow Chambers



Human Neutrophils Rolling on
Human Endothelial Cells Expressing E-selectin

Parallel plate flow chambers are used in dynamic studies of cell adhesion under well-defined shear forces. Various gasket sizes allow flexibility in experimental design to operate with limited quantities of cells and/or reagents.

(Refer to Protocol 7)

Circular Flow Chamber (for 35mm tissue culture dishes)

31-001

Circular Flow Chamber Kit

Technical Reference: Improvements to Parallel Plate Flow Chambers to Reduce Reagents and Cellular Requirements, Brown and Larson, BMC Immunology 2001, 2:9



Flow Chamber Kit Includes:

Two flow decks
(cast acrylic with different inlet/outlet designs)

8 silicon rubber gaskets (two of each size)
Flow Width = 0.25 cm, Thickness = 0.005 in
Flow Width = 0.25 cm, Thickness = 0.010 in
Flow Width = 0.50 cm, Thickness = 0.010 in
Flow Width = 1.00 cm, Thickness = 0.010 in

24 polypropylene tubing connectors (six of each)
Threaded 1/16 in. straight and L-connectors
Male and Female taper luer to 1/16 in. connectors

Silastic� laboratory tubing (1/16 in. ID x 10 ft.)


Replacement Gaskets and Coverslips for the Circular Flow Chamber
31-002Four Gaskets  (Flow Width = 0.25 cm, Thickness = 0.005 in)$30.00



31-003Four Gaskets  (Flow Width = 0.25 cm, Thickness = 0.010 in)$30.00



31-004Four Gaskets  (Flow Width = 0.50 cm, Thickness = 0.010 in)$30.00



31-005Four Gaskets  (Flow Width = 1.00 cm, Thickness = 0.010 in)$30.00



31-008Circular Glass Coverslips (pack of 30, 35 mm, #2)$30.00





Rectangular Flow Chamber (for standard microscope slide)

31-010

Rectangular Flow Chamber Kit







Flow Chamber Kit Includes:

One flow deck (cast acrylic)

4 silicon rubber gaskets (two of each size)
Flow Width = 1.00 cm, Thickness = 0.005 in
Flow Width = 1.00 cm, Thickness = 0.010 in

24 polypropylene tubing connectors (six of each)
Threaded 1/16 in. straight and L-connectors
Male and Female taper luer to 1/16 in. connectors

Silastic� laboratory tubing (1/16 in. ID x 10 ft.)


Replacement Gaskets for the Rectangular Flow Chamber
31-011Four Gaskets  (Flow Width = 1.0 cm, Thickness = 0.005 in)



31-012Four Gaskets  (Flow Width = 1.0 cm, Thickness = 0.010 in)
