DSX110 三维超景深显微镜
- 型号：DSX110
- 供应商：北京元中锐科集成检测技术有限公司
- 供应商报价：面议
- 标签：三维超景深显微镜,-1,北京元中锐科集成检测技术有限公司
产品库
| DSX110 超景深数码显微镜技术参数： | |||
| Main frame | Zoom ratio | Optical zoom | DSXPLFL3.6X/1X: 1X to 16X (max) XLMPLFLN10XDSX (with DSX-LEDAD10X): 4X to 16X (max) |
| Digital zoom | 17X to 30X | ||
| Mountable objective lens | DSX dedicated objective lens | DSXPLFL1X, DSXPLFL3.6X, XLMPLFLN10XDSX DSX-LEDAD10X | |
| Illumination (Objective lens) | LED ring light illumination | ||
| Camera | Image sensor | 1/1.8 inch, 2.01 megapixels, color CCD (total pixels: 2.10 megapixels) Total pixels : 1688 (H) x 1248 (V) Available pixels : 1628 (H) x 1236 (V) Effective pixels : 1600 (H) x 1200 (V) | |
| Cooling method | Peltier cooling | ||
| Scan mode | Progressive scan | ||
| Frame rate | 15 fps/27 fps with binning mode | ||
| Image size | Normal : 1194 x 1194 (1:1)/1592 x 1194 (4:3) Fine : 1194 x 1194 (1:1)/1592 x 1194 (4:3) Super fine : 3594 x 3594 (1:1)/4792 x 3594 (4:3) | ||
| Sensitivity | ISO 100/200/400/800/1600 equivalent | ||
| Fine focusing (Motorized) | Stroke | 34 mm | |
| Resolution | 0.4 μm | ||
| Frame | Coarse focusing (Manual) | Stroke | 50 mm |
| Maximum sample height | Standard | 80 mm*1 | |
| To ensure U-centric operation in tilted operation | 50 mm*2 | ||
| Tilt mechanism | Type | Manual, lock/release handle | |
| Tilt angle | Left/Right 45° | ||
| Stage | DSX-UFSSU (Motorized)*3 | Stroke | 100 x 100 mm |
| Load capacity | 1 kg | ||
| U-SIC4R2 (Manual) | Stroke | 100 x 105 mm | |
| Load capacity | 1 kg | ||
| LCD monitor | Size | 23” with touch panel and Full HD color LCD monitor | |
| Resolution | 1920 (H) x 1080 (V) | ||
| Weight (Main frame, Manual stage, LCD monitor, Control box, Controller) | Approx. 36.5 kg | ||
| Input rating | 100-120 V/220-240 V, 300 V A, 50/60 Hz | ||
*1 50 mm in case of the combination with DSX-UFSSU (not included BH2-WHR43/wafer holder plate)
*2 20 mm in case of the combination with DSX-UFSSU (not included BH2-WHR43/wafer holder plate)
*3 DSX-WZ-STAD is required to install
| DSX110 Objective Lens | ||||||
| Series | Model | Parfocalizing distance | NA | W.D. (mm) | Actual F.O.V. (μm)*1 | Total magnification*2 |
| DSX dedicated objective lens | DSXPLFL1X | 167 mm | 0.025 | 138*3 | 57,447-3,591 | 7X-107X |
| DSXPLFL3.6X | 79 mm | 0.09 | 50*4 | 15,958-997 | 24X-386X | |
| XLMPLFLN10XDSX DSX-LEDAD10X | 79 mm | 0.27 | 30 | 1,437-359 | 268X-1,071X | |
*1 At aspect ratio 1:1 diagonal (with factory default value) *2 At aspect ratio 1:1
*3 123 mm in case of the combination with the DSX-POAD1X *4 35 mm in case of the combination with the DSX-POAD3.6X
