MT12-13-14 索尼Magnescale传感器信号转换器MT12-13-14
- 型号：MT12-13-14
- 供应商：湖南新化万濠精密仪器服务有限公司
- 供应商报价：面议
- 标签：索尼Magnescale传感器信号转换器MT12-13-14,-1,湖南新化万濠精密仪器服务有限公司
产品库
| 品牌 | Scale/仁沃 |
|---|
Interpolators for DT12 / 32 Series
| Specifications | ||||||||
|---|---|---|---|---|---|---|---|---|
This product might change without a previous notice for the improvement, confirm the function and the performance with the latest specifications. | ||||||||
| Model | MT12-05 | MT12-10 | MT13-01 | MT13-05 | MT13-10 | MT14-01 | MT14-05 | MT14-10 |
| Compatible measuring unit | DT512, DT12/DT32 | |||||||
| Maximum response speed | 100 m/min | |||||||
| Maximum resolution | 5μm | 10μm | 1μm | 5μm | 10μm | 1μm | 5μm | 10μm |
| Power supply Power supply voltage | DC5 V ±4 % | |||||||
| Power consumption | 0.9 W | 1.2 W (when output load of 120Ω is connected) | ||||||
| Output format | NPN open collector | Voltage differential line driver | ||||||
| Operating temperature/humidity | 0 to +50 °C (non condensing) | |||||||
| Storage temperature/humidity | -10 to + 60℃ (20 to 90 %RH) | |||||||
| Mass | Approx. 90g | |||||||
