CN7263控制器 美国omega数显控制器温控

CN7263控制器 美国omega数显控制器

1/4 DIN斜坡/恒值温度/过程控制器
CN7200 Series
1年保修 新产品! CE
1/4 DIN斜坡/恒值温度/过程控制器
CN7200 Series:1/4 DIN斜坡/恒值温度/过程控制器
双4位数的LED显示屏
8斜坡/恒值程序段，每8
通用输入
调谐
双控制输出
RS-485通信
自由软件
报警功能
the cn7200系列?din温度/过程控制器are designed to accept热电偶、RTD电流或电压，输入和输出提供双for控制。可用的输出包括中继/继电器、直流脉冲/继电器，电流/电压继电器，或线性/中继。the units can be程控for ON / OFF，PID自整定，然而，手动调谐控制方法。PID控制是supported by the 64斜坡/香皂的行动。cn7200系列also includes two the additional报警输出。第二继电器输出可以reconfigured as a third报警输出。报警类型can be selected从13不同preprogrammed报警功能。双LED显示控制器的功能在本地指示of process and setpoint收益。
规格
Inputs: Thermocouple, RTD, DC voltages or DC current
Display: Two 4-digit, 7-segment
PV: red, 19 mm (3.4") H
SV: green, 12.7 mm (1.2") H
Accuracy: ±0.25% span, ±1 least significant digit
Supply Voltage: 100 to 240 Vac, 50/60 Hz
Power Consumption: 5 VA max
Operating Temperature: 0 to 50°C (32 to 122°F)
Memory Backup: Nonvolatile memory
Control Output Ratings:
Relay: SPDT, 5 A @ 250 Vac resistive
Voltage Pulse: 14V, 10 to -20% (max 40 mA)
Current: 4 to 20 mA
Linear Voltage: 0 to 5V, 0 to 10V
Communication: RS-485 MODBUSR A-5-11/RTU communication protocol
Panel Cutout: ?DIN, 92 mm square (3.622" square)
Dimensions: 96 x 96 x 15.8 mm bezel (3.78 x 3.78 x 0.625")
Panel Depth: 79.2 mm (3.125")
Weight: 425 g (15 oz)
Front Panel Rating: IP66

产品型号  产品描述
CN7223 Dual output, DC Pulse/relay with RS-485*
CN7233  Dual output, relay/relay with RS-485*
CN7253  Dual output, 4 to 20 mA/relay with RS-485*
CN7263  Dual output, 0 to 5, 0 to 10 Vdc/relay with RS-485*
选配件
CNQUENCHARC Noise Suppression RC snubber (2 leads), 110 to 230 Vac
OMX-R250 250Ω precision resistor
CN7-485-USB-1 RS-485 to USB Mini-Node Converter
