Differential-Hall-Effect Series A5S...
Your first choice for permanent installation. Detecting small and large steel profiles (gear wheels, slots, holes). Outstanding performance under hard ambient conditions: Speed range 0... 12,000 pulses per sec, equally high and powerful output over  theentire range, adequate for transmission over more than 500 meters. Level approximay that of supply voltage. Profile size down to gear m 0,8 (pitch 32), slot or hole width down to 3 mm. Gap (clearance) to target nearly up to 4 mm. Their differential principle fights the influence of other magnetic fields and machine vibration. Sealed (>200 bar) stainless steel enclosure with smooth or threaded shaft 5/8UNF, or M12, M14, M18, or M22, length as option

Temperature -40°C ...+125°C ( -40 ... +255 °F). Connection via tight plug or firm cable.

Specific application characteristics of A5S... series:

Series No.

Application Characteristics

Special Notes

A5S05
…A5S09..

Satisfying all standard applications requiring single trace frequency output. Typical: turbines, motors, process machinery

A5S10 …A5S13..

speed detection in Ex-areas, grade EExia IIC T4  (Div 1 and Div 2, class I group A..D, class II group E...G)

use  with Separating Barrier D461.11

Supply < 9.9 volts

A5S30 …A5S33..

direction sensing incorporated. 1 trace as speed signal frequency,

1 trace as binary signal forward/reverse. Typical:  feeder pumps

requires gear size > m2 (pitch  4 mm

A5S14 …A5S17

direction sensing as above, within Ex-areas

use  with Separating Barrier D461.21

A5S40 …A5S43

double trace frequency output, for external direction evaluation with failure detection. Typical: monitored direction detection

requires gear size > m2 (pitch  4 mm

Opto-electronic Sensor Series A1S...

Applicable to all objects, including plastic parts (fan blades, for instance). A  not profiled target (smooth shaft, for instance) will be easily marked  by a paint dot or by our adhesive reflective tape. Local environment should be kept clean. Signal conditioning in evaluation unit recommended, as provided by our C118, C156, or E1519 units.
Speed range 0/10 ...20,000 pulses per sec. Connection detachable with plug, or tight by firm cable. Signal transmission up to 10 meters (as standard), A1S40 up to 100 meters.   Specific application characteristics of A1S... series:

Model No.

Application Characteristics

A1S30... A1S36..

easy handling, the favourite for variable use. Scanning distance 1...2 cm (depending on reflection).Sensor shaft 8 mm Ǿ, length 35 or 95 mm. Supply typically by evaluating unit.

A1S37P

Laser type reflection sensor with scanning distance up to 2 meters. Laser beam < 3 mm in Ǿ, thereby sharp resolution. Requires marking with reflective tape U1A006.

A1S40

Infrared reflection sensor. Cylindrical enclosure with mounting thread M30. Scanning distance up to 50 cm. Optional fibre glass adapters for extreme conditions (temperature up to 300 °C, for instance).

Proximity Type sensor series A4S....

Applicable to larger sized profiles of steel or non-ferrous material. Allowing a large gap(clearance) between sensor and target: useful at a center displaced wheel, or if particles have to pass between sensor and target. Range from zero up to medium speed. Typical feeder belts, blades.  Characteristics vary widely between different models.

Click here for datasheet

Magnetic pick-up sensor series A2S...

德国工控仪器备件：原装进口，超短货期，质量保证
代理总负责人：祝晓斌
P: &
T:
:
：colin@origist.com
http://www.origisth.com/

Detecting speed of rotating steel profiles, specifically at high speed, and under high temperature (turbines, turbo-blowers, for instance). Also, the alternating magnetic field around transformers, ignition coils, or rotating magnetic parts. Output signal varies with frequency and gap, therefore requiring high sensitivity of the receiver input, or a local pre-amplifier.
Not for low speed applications.These sensors do not require supply. Various design models available.

Click here for data sheet

Wheel Pulse Transmitters
Detecting speed and material length when run on a web, or on the surface of a cylinder.Specifically used with plastic and metallic foils, and with paper and textile machines. Speed range up to 3000 m/min. Resolution up to 1 pulse per millimeter. All models have a high output allowing signal transmission over 100 meters.  Click for data sheet.

Model No

Resolution

Speed Range

Accuracy

A1L04B200

1 pulse/mm

0 ...2000 m/min

0,5 %

2 wheels of 64 mm Ǿ

A1L05B500

1 pulse/mm

0 ...3000 m/min

0,5 %

2 wheels of 160 mm Ǿ

Incremental Encoders G1000
For permanent installation. Connecting to the end of an open shaft. Available with up to 5000 pulses / rev. Speed range 0 ....6000 RPM. Signal frequency up to 20 kHz. Available with single or double trace for direction sensing. Typical winders, cranes. High output allowing signal transmission over 100 meters.
