STR3030A1 三相标准源（中）英文版

本产品由上海徐吉电气有限公司精心推荐：

产品特性：

1      adopts touch screen control panel to add the mask button, display information, simple to use convenient.
2     Embedded watt-hour meter high standard power, and as a standard for digital closed loop feedback, voltage, current, frequency, phase and active power, reactive power, apparent power, power factor and so on various parameters can be used as the standard.
3     With multiple protection function: current limiting protection, power protection, voltage protection, short circuit protection, current open power amplifier thermal protection, and other functions.
4     three-phase voltage current loop independent control, each phase voltage and current ouXUJIut parameters can be adjusted separay.
5     Smart gear: within the scope of the instrument allows the ouXUJIut, the user can set arbitrary three-phase voltage current gear their rated voltage, current, voltage and current of the sites, the fineness of adjustment of nominal gear is set by the user reference, easy operation.
test voltage, current, phase, rich, easy to operation.

产品参数：

1.1 OuXUJIut power:
      voltage: 10-456 v voltage (internal gear 57.7, 100, 220, 100 v), the maximum ouXUJIut power 20 va.
      current: 0.001-12 a (a) 24 (internal current gear 1, 2.5, 5, 10 a (20 a)), the maximum ouXUJIut power 20 va.
      ouXUJIut frequency: 45-65 hz.
      ouXUJIut phase: 0-359.99 °.
      stability: 0.1 the following voltage, current, power stability is less than 0.02%, 0.05 voltage, current, power stability is less than 0.01%.
      distortion: internal gear rated ouXUJIut, voltage and current distortion degree is less than 0.5% (not a capacitive load).
      Harmonic: 2-31, total harmonic content is not more than 40% of the fundamental wave, multiple superposition.
1.2 Accuracy of the ouXUJIut and display:


1.3 Commonly used ouXUJIut control sites
Voltage test: 80%, 90%, , 110%, .
Current sites: 1%, 5%, 10%, 20%, 50%, , 50% and 400%.
Phase sites: 0.5 L and 0.8 L, 1.0, 0.8 C and 0.8 C.
Three phase voltage and current amplitude can be regulated respectively, adjust fineness: 10%, 1%, 0.1%, 1%; The adjusting range is the largest to 125%.
Three phase voltage, phase current, power factor can also be split phase adjustment, adjust the fineness of 10 ° respectively, 1 ° and 0.1 ° and 0.01 °.
UB, UC respectively for UA phase can also regulate respectively.
Frequency of adjustment is three-phase voltage and current adjustment, adjust the fineness of 5 hz, respectively
1 Hz, 0.1 Hz, 0.1 Hz.
1.4 power supply
Single-phase AC 180-265 - v, 50/60 hz.
1.5 external size: 440 * 400 * 133 mm
1.6 Weight 18Kg。
