ALTEK MODEL 9009BL1V ALTEK MODEL 9009BL1V

MODEL 9009BL1V
CAN PRESSURE/VACUUM BUCKLE TEST STATION FOR FOOD/UTILITY CANS
FEATURES
?TEST UP TO 404 DIAMETER
?AIR OPERATED (NO ELECTRICITY IS REQUIRED)
?ADJUSTABLE FILL/VACUUM RATE
?LARGE, EASY-TO-READ GAUGE
?LAZY HAND INDICATOR
?TEST POINT FOR CALIBRATION
?WIDE RANGE OF CHANGE PARTS
?SELF-ADJUSTING CAN CLAMPS
?EXTENSIVE SAFETY FEATURES

WEIGHT/DIMENSIONS …… 125# / 21" w ×  22" h ×  21" dp

PNUEMATIC:  Supply Connection …… male 1/8 npt fitting

            Supply Pressure ……   150 psig max

Supply Delivery ……   1 cfm min

OPERATION:  External Regulator …… 100 psig max (adjustable)

            Test Regulator ………… 60 psig max (adjustable)

            Clamp Regulator ……80 psig nom, 100 psig max (adjustable)

           Press/Vac Flow Rate…… needle valve adjustable

           Vacuum Capability ……  0 - 25"  hg

           O-Ring Lubrication …PARKER SUPER O-LUBE or equiv

           Sample Capacity …………404 dia, 800  hgt

                                  (4 4/16" dia  8" hgt)

OUTPUT:    Readout …………    4"  dia. Bourdon tube gauge,

                                w/ lazy hand indicator

           Range ……………… 0-30" hg / 0-60 psig

          Graduation ………… 1"hg / 1 psig
