SBD3103 SBD3103-G不锈钢防爆灯，SBD3103-q防爆钢材灯

 SBD3103不锈钢【铝材】防爆灯

·························································································································································

技术参数：

      1、额定电压：220V / 50Hz

      2、光源：MH气体放电灯   功率  250W
           光通量       21000lm
           平均使用寿命   10000h


           HPS气体放电灯  功率  250W
           光通量       27500lm
           平均使用寿命   15000h


      3、防爆标志：Exd II CT4

      4、灯座规格：E40

      5、防护等级：IP66

      6、引入口规格：G3/4”

      7、引入电缆外径：Ф8~Ф14mm

      8、灯具外形尺寸：Ф215×392mm

      9、灯具重量：6.1kg

 SBD3103不锈钢【铝材】防爆灯

·························································································································································

 注意事项：

1、灯具安装后，供电前应检查灯具的接线方式是否正确，安装是否牢固，确保安全后才可正常供电；

2、安装及更换灯泡时，应使用相同类型、功率的灯泡；如果改变灯泡类型或功率，应更换相应配套的镇流器；

3、灯具表面有一定的温升，属正常现象；透明件ZX温度较高，不得触摸；

4、光源冷启动时间为（3～10）分钟，灯泡在高温状况下不能重启动属正常现象，建议等灯泡稍微冷却后再启动；

5、拆装、维护灯具时，应由专业人员操作，发现有不正常现象应断电报修，不是专职维修人员不准擅自进行维修；

6、操作前必须先断开电源，同时确保灯具可靠接地。

 SBD3103不锈钢【铝材】防爆灯

·························································································································································

性能特点：

1、优良的防爆性能，防护性能高达IP66，户内、户外使用均可；

2、壳体采用轻质合金材料和高科技喷涂技术,确保在潮湿和高温恶劣环境中永不腐蚀生锈；

3、选用优质的进口气体放电光源，光效高，光源的使用寿命更长、性能更可靠、使用更放心；

4、工作性能稳定、功耗和温升低、使用寿命长；另外还加装补偿电容，功率因数高达0.90以上；

5、安装方式齐全，常规有吸顶式、壁式、吊杆式、立杆式、护栏式等，也可根据用户现场要求特制其它形式的安装方式；

6、本灯具进线口设有专用电缆引入装置，密封性能良好，可直接钢管或电缆布线。
