具有RS232输出数字扭矩仪
HHTQ88
Digital Torque Meter with RS232 Output
Three Selectable Torque Units: kgf-cm, lb-in, N-cm
High and Low Resolution Modes
Fast and Slow Sampling Modes
Auto Shut-Off Extends Battery Life
Reading Hold
Stores Minimum and Maximum Readings with Push-Button Recall
RS232 PC Interface to Load Data into Your Logging or Recording Programs
The HHTQ88 is a precision test instrument for automotive, automation, laboratories, and general industrial applications. The unit comes complete with the torque sensor with built-in 12 mm (0.5") chuck and chuck key. Three selectable torque units (kgf-cm, lb-in, N-cm) give this instrument almost universal compatibility with all measuring systems. The HHTQ88 also has fast and slow sampling rates to fit most automation applications. The readings are easy to read, displayed in large 15 mm (0.6") high digits. The RS232 serial interface allows you to download data for use in your data logging or recording programs.
规格
Units: kgf-cm, lb-in, N-cm (N = Newtons)
Range: Up to 15 kgf-cm
Safe Overload: 150% of range
Functions: Auto off (after approx 20 min), reading hold, min and max
Accuracy: ±1.5% FS +5 digits, 23 ±5oC, includes linearity, repeatabilityand hysteresis
Operating Temperature: 0 to 50oC (32 to 122oF)
Operating Humidity:<80% RH (non-condensing)
Sensor Chuck: 12 mm (0.5")
Power: 9 V alkaline battery (included)
Sampling Time:
Fast: Approximay 0.125 sec
Slow: Approximay 0.334 sec
Data Output: RS232 PC serial output
Meter Dimensions: 180 x 72 x 32 mm (7.1 x 2.8 x 1.3")
Sensor Dimensions: 48 D x 160 mm L (1.9 x 6.3")
Meter Weight: 225 g (0.5 lb)
Sensor Weight: 665 g (1.5 lb)
Sensor Cable: 1 m (39")
产品型号/产品描述
HHTQ88 Handheld torque meter
SW-U101-WIN Software and cable for HHTQ88
注释: Comes complete with battery, meter, torque sensor, chuck key, hard carrying case and operator’s manual.
