建筑材料可燃性试验炉GB

 北广精仪生产建材可燃试验炉（中英文版简介）

One, overview

试验前详细阅读国家标准GB8626《建筑材料可燃性试验方法》，对您的试验工作将有很大帮助。

Before the test detailed reading of the national standard GB8626 "building materials flammability test method", will be a great help to test your work.

建材可燃性试验炉是判定在规定的条件下，建筑材料是否具有可燃性的试验方法，是根据国家标准GB8626规定的技术参数而研制的。

Building materials flammability test furnace is determined under specified conditions, test methods for building materials are flammable, is developed according to the technical parameters of national standard GB8626 requirements.

二、 仪器的工作环境及主要技术指标

Two, the instrument working environment and the main technical indicators

1. 环境温度：15℃～25℃；

1 ambient temperature: 15 ℃ ~ 25 ℃;

2. 相对湿度：≤85％；

Relative humidity: 2 ≤ 85%;

3. 供电电压和功率：220V 50HZ 100W；

3 power supply voltage and power: 220V 50HZ 100W;

4. 气源：液化石油气；

The 4 source: liquefied petroleum gas;

5. 本生灯对式样施加火焰时间15s；

5 Bunsen flame time of applying 15s;

三、 式样尺寸：采用边缘点火90×190mm；采用表面点火90×230mm，每组试验需5个试件。

Three, sample size: the edge of the ignition 90 * 190mm; the surface ignition of 90 × 230mm, 5 specimens of each test.

四、 试验步骤

Four, the test procedure

1. 检查仪器面板上的时间显示器设定值是否在标准值。

Time display 1 check the instrument panel on the set value is in the standard value.

2. 接通电源、气源，把仪器面板上的“燃气开关”阀向右调到Z小，打开钢瓶阀门。

2 switch on the power, gas source, the instrument panel on the "gas valve switch" right to minimum, open the cylinder valve.

3. 打开电源开关，按“复位”键使燃烧器复位。

3 turn on the power switch, press the "reset" button to reset the burner.

4. 打开燃烧箱门，将装有试件的试件夹固定在燃烧箱内，按“运行”键后，根据试件的情况调节试件夹与燃烧器的距离，再按“复位”键使燃烧器返回。

4 open combustion chamber door, with the specimen clamp is fixed in the combustion box, press the "working" button, according to the situation of specimen clamp and the distance from the burner regulation, then press the "reset" button to return to the burner.

5. 向左“燃气开关”用点火器键点着燃烧器，调节火焰高度到20mm±2mmm，关闭箱门。

5 left "gas switch" with a burner for ignition key, adjust the flame height to 20mm ± 2mmm, close the door.

6. 按“运行”键，使燃烧器对试件施加火焰15s，施加火焰完毕后，燃烧器自动移去，计量从点火开始至火焰到达刻度线或试件表面燃烧火焰熄灭的时间，按“计时”键仪器面板上的时间显示器停止，并记录此数据。

6 according to "run" button, the burner flame of 15s applied to the test piece, applied after the burner flame, automatic removal, measurement from ignition to fire to scale line or specimen surface combustion flame extinction time, press the "timing" button on the instrument panel display the time stop, and record the data.

7. 重复做5个试件后，关掉电源，“燃气开关”及钢瓶阀门，对燃烧箱、试件积进行必要的维护。

7 repeat 5 specimens, turn off the power, "gas switch" and the cylinder valve, to the combustion chamber, sample product necessary maintenance.

8. “复位”：在试验过程中未到15s，火焰尖头已达刻度线，按“复位” 键移去燃烧器。

8 "reset": 15s not to in the course of the experiment, the flame tip has reached the scale line, press the "burner reset" button to remove.

五、 材料可燃性的判定

Five, the determination of the flammability of materials

经试验符合下列规定的建筑材料均的确定为可燃性建筑材料：

The test in accordance with the following requirements of the building materials were identified as combustible building materials:

1. 对下边缘未加保护的试件，在底边缘点火后开始后的20s内，五个试件火焰尖头均未到达刻度线。

1 on the lower edge of the specimen without protection, at the beginning of the bottom edge of the ignition after 20s, five specimens are not to scale line flame.

2. 对下边缘加以保护的试件，除符合（1.）规定外，应附加一组表面点火试验，点火开始后20s内，五个试件火焰尖头均未到达刻度线。

2 on the lower edge of the specimen protection, in addition to the （1） provided, should be added a set of surface ignition, ignition started after 20s, five specimens are not to scale line flame.

六、 装箱清单

Six, packing list

序号 名 称 单位 数量

The number of serial number name unit

1 建筑材料可燃性试验机 台 1

1 building materials flammability test machine station 1

2 产品说明书 本 1

2 of the 1 product specification

3 产品合格证 个 1

3 product certificate 1

4 电源线 条 1

4 power line 1

5 煤气管（带卡扣） 条 1

5 gas pipe （belt buckle） 1

6 夹具 套 2

The 6 clamp sleeve 2

7 火焰高度量具 个 1

7 flame height gauge 1

8 燃烧器定位器 个 2

8 burner locator 2
