进口潜水电磁阀
- 产地：德国
- 供应商：广州阀门有限公司
- 供应商报价：面议
- 标签：进口潜水电磁阀,-1,广州阀门有限公司
产品库
| 产品规格： | DN15--DN300 |
| 阀体材质： | 铸钢体、不锈钢（铸钢体不能用在腐蚀流体上） |
| 适用介质： | 水、气、油、腐蚀流体等 |
| 温度范围： | -20～+100℃ |
| 介质粘度： | 小于50C St（大于时需定制） |
| 防护性能： | 防水、防爆（Exd IICT5）、防腐 |
| 接线方式： | 引线式 |
| 控制方式： | 常开、常闭 |
| 电源电压： | DC24～127V; AC36～380V |
| 连接方式： | 内螺纹、法兰（外螺纹和特殊接口可定做或加转接头） |
| 泄 漏 量： | 零 |
| 产品代码 | GN819 |
| 公称通径 | 选用《LIKZCD系列直动式电磁阀》、《LIKZC系列中低压电磁阀》、《LIKZCG系列高压电磁阀》中的标准口径 |
| 适用压力 | 选用《LIKZCD系列直动式电磁阀》、《LIKZC系列中低压电磁阀》、《LIKZCG系列高压电磁阀》中的压力范围 |
| 连接尺寸 | 选用《LIKZCD系列直动式电磁阀》、《LIKZC系列中低压电磁阀》、《LIKZCG系列高压电磁阀》中的接口尺寸 |
| 阀体体质 | 铸铁、铸钢、不锈钢 |
| 特殊功能 | （其它功能可定制） |
| Specifications: | DN15 - DN300 |
| Body material: | Steel body, stainless steel （steel body can not be used in corrosive fluid on） |
| Medium: | Water, gas, oil, corrosive fluids |
| Temperature range: | -20 ~ +100 ℃ |
| Media Viscosity: | Less than 50C St （greater than the time to be customized） |
| Protection performance: | Waterproof, explosion-proof （Exd IICT5）, anti-corrosion |
| Wiring: | Leaded |
| Control: | Normally open, normally closed |
| Power supply voltage: | DC24 ~ 127V; AC36 ~ 380V |
| Connection: | Thread, flange （male and special interfaces or add custom adapter） |
| Leakage: | Zero |
| Product Code | DM819 |
| DN | Use "LIKZCD Series direct-acting solenoid valve", "LIKZC series of low pressure solenoid valve", "ZCG series of high-pressure solenoid valve" in the standard diameter |
| Apply pressure | Use "LIKZCD Series direct-acting solenoid valve", "LIKZC series of low pressure solenoid valve", "LIKZCG series of high-pressure solenoid valve" in the pressure range |
| Connection size | Use "LIKZCD Series direct-acting solenoid valve", "LIKZC series of low pressure solenoid valve", "LIKZCG series of high-pressure solenoid valve" in the interface dimensions |
| Body Constitution | Cast iron, cast steel, stainless steel |
| Special Features | （Other functions can be customized |
