burkert 0450阀组宝帝0450阀岛The multi-way valve Type 0450 HazEx™ brings Burkert’s Type 0450 centralized process actuation solution to hazardous areas.burkert 0450阀组宝帝0450阀岛 Its high flow rates in combination with the aluminum bodies allow a wide range of applications. Most commonly used safety barriers are approved for applications with the Type 0450 HazEx™. For easy installation, the valves can (on request) be supplied pre-wired to WAGO and Harting junction boxes.

特点：

1. EEx ia IIC T6 approved
2. Optimized System Solutions for hazardous areas
3. High Flow Rates
4. Long service life even with non-lube conditions
5. Pre-tested and supplied easy to connect

参数：

Valve type 0450 HazEx™
Materials
Valve body Aluminum anodized
Valve internals Al, St.Steel, brass
Seals POM/NBR
Pneumatic modules Aluminum anodized
Fluids Filtered compressed air, lubricated or unlubricated

Manual override Standard
Valve port connection G1/8
Rating IP 65 with plugs
Power supply 24 V/DC
Intrinsically safe barrier Required
Ambient Temperature
Pi = 0.7 W 14 up to 122°F at T6
Pi = 0.9 W 14 up to 140°F at T5
Configuration To customer requirement

Electrical connection options Cable plug 2506
EaseOn cable plug 2510
Prewired junction boxes WAGO (on request)
Harting (on request)
