DSY-110ZA 自动冷滤点测定器 Automatic Cold Filter Plugging Point Tester
适用标准：SH/T0248 ASTM D6371
性能特点：
- 采用金属浴( 02210773.8)，降温速度快，从48℃降至-68℃≤15分钟。
- 试样在一个浴内完成所有温度点的测定。
- 双浴双孔，浴温可分别控制。
- 8英寸彩色触摸显示屏，微电脑控制，具有自动吸滤，光电检测样品，自动计时、自动判断试验结果、自动保存试验结果。
- 功能丰富，用户可任意添加试样名称，设有修改权限密码，可储存大量试样结果，便于用户查询。
- 可连接LIMS系统。
- 技术参数：
- 降温速度：从48℃降至－68℃≤15分钟
- 浴温每下降17℃≤150秒
- 控温范围：48℃～-68℃
- 控温精度：±0.5℃
- 停机间隔时间：＞30min
- 整机功率：1800W
- 外形尺寸：580×580×626（mm）
- 主机重量：91kg
- 工作电源：AC220V±10% 50Hz
Applicable standards：SH/T0248 ASTM D6371
Performances:
- Metal bath(Patent No:ZL 02210773.8), fast temperature drop, from 48℃to -68℃≤15min.
- All temperature points can be tested in one bath.
- 2 test holes which can be controlled separay.
- 8" color display, embedded computer control, all process can be operated automatically
including suction and filtration, light-electric detection, timing, test result judgement and save results.
- Rich function, Client can set sample name freely. Password has been set for modify
authority, lots of test results can be saved. it is easy for client to reference.
- LIMS is possible.
- Technical parameters:
- Temperature drop rate: from 48℃ to -68℃≤15min
- Temperature drop 17℃≤150s
- Temperature control range:48℃～-68℃
- Temperature control precision:±0.5℃
- Interval between two test:＞30min
- Power: 1800W
- Size: 580×80×626 (mm)
- Weight: 91kg
- Electrical Requirements: AC220V±10%. 50Hz
