L Agilent HP L 系列经济型机电开关/L 系列经济型机电开关

产品信息
品牌 安捷伦

Agilent HP L 系列经济型机电开关/L 系列经济型机电开关

详细资料：

产品
配置
寿命
插损重复性
隔离
性能特性
L7104A
SP4T, terminated
2 million
0.03 dB
90 dB at 12 GHz
位置指示，内有控制逻辑，磁锁存
L7204A
SP4T, unterminated
2 million
0.03 dB
90 dB at 12 GHz
位置指示，内有控制逻辑，磁锁存
L7106A
SP6T, terminated
2 million
0.03 dB
90 dB at 12 GHz
位置指示，内有控制逻辑，磁锁存
L7206A
SP6T, unterminated
2 million
0.03 dB
90 dB at 12 GHz
位置指示，内有控制逻辑，磁锁存

L7104A Multiport Coaxial Switch, DC to 4 GHz, SP4T
L7204A Multiport Coaxial Switch, DC to 4 GHz, SP4T
L7106A Multiport Coaxial Switch, DC to 4 GHz, SP6T
L7206A Multiport Coaxial Switch, DC to 4 GHz, SP6T
主要技术指标
特点
·                                                                                                                                                                                                   SP4T 配置, 有负载端/无负载端
·                                                                                                                                                                                                   电子位置指示
·                                                                                                                                                                                                   电流中断能力
·                                                                                                                                                                                                   磁锁存
超级的 RF 性能
·                                                                                                                                                                                                   无与伦比的隔离度, 典型 90 dB Z小
·                                                                                                                                                                                                   保证0.03 dB 的插损重复性
·                                                                                                                                                                                                   200万次的寿命

安捷伦L7104/6A系列多端口开关提高了射频和微波信号传输以及测试应用的准确度。其经济性价格的机电开关具有无可匹敌的隔离度和仅0.03dB插入耗损重复性,使用寿命达两百万次。L7104/6A系列的极低重复插损减少了测量中的随机误差源，因此提高了测量精度。这些开关的重复性和可靠性使得测量准确性得以保证,减少了校准周期、增加了测试系统的正常运行时间，从而降低了企业成本。安捷伦严密的设计制造规格成就了L7104/6A的高重复开关性能。

安捷伦L7104/6A系列多端口开关不仅在信号监测和输入应用方面性能优越，而且价格经济，是系统集成测试工程师的理想选择。

典型配置
               L7104A     Switch, SP4T, dc-4 GHz, terminated （L-SERIES）
·                                                                                                                                                                                    L7104A-100 Solder terminals  焊接终端（接线端）
·                                                                                                                                                                                    L7104A-024 24 VDC
·                                                                                                                                                                                    L7104A-T24 24 VDC bias with TTL logic
·                                                                                                                                                                                    L7104A-161 16-pin DIP socket and connector with 24 inch ribbon cable
·                                                                                                                                                                                    （DIP插座和带24英寸橡胶线的连接器）



产品
配置
寿命
重复性
隔离
性能特性
L7104B
SP4T, terminated
2 million
0.03 dB
90 dB at 12 GHz
Position indicator, internal control logic, magnetic latching
L7204B
SP4T, unterminated
2 million
0.03 dB
90 dB at 12 GHz
Position indicator, internal control logic, magnetic latching
L7106B
SP6T, terminated
2 million
0.03 dB
90 dB at 12 GHz
Position indicator, internal control logic
L7206B
SP6T, unterminated
2 million
0.03 dB
90 dB at 12 GHz
Position indicator, internal control logic, magnetic latching

L7104B Multiport Coaxial Switch, DC to 20 GHz
L7204B Multiport Coaxial Switch, DC to 20 GHz, SP4T
L7106B Multiport Coaxial Switch, DC to 20 GHz, SP6T
L7206B Multiport Coaxial Switch, DC to 20 GHz, SP6T
主要技术指标
特点
·                                                                                                                                                                                                   SP4T/SP6T 配置, 有负载端/无负载端
·                                                                                                                                                                                                   电子位置指示
·                                                                                                                                                                                                   电流中断能力
·                                                                                                                                                                                                   磁锁存
超级RF性能
·                                                                                                                                                                                                   无与伦比的隔离度, 典型 90 dB at 12 GHz
·                                                                                                                                                                                                   保证0.03 dB 插损重复性
·                                                                                                                                                                                                   200万次寿命
安捷伦L7104/6B系列多端口开关提高了射频和微波信号传输以及测试应用的准确度。其经济性价格的机电开关具有无可匹敌的隔离度和仅0.03dB插入耗损重复性,使用寿命达两百万次。L7104/6B系列的极低重复插损减少了测量中的随机误差源，因此提高了测量精度。这些开关的重复性和可靠性使得测量准确性得以保证,减少了校准周期、增加了测试系统的正常运行时间，从而降低了企业成本。安捷伦严密的设计制造规格成就了L7104/6B的高重复开关性能。

安捷伦L7104/6B系列多端口开关不仅在信号监测和输入应用方面性能优越，而且价格经济，是系统集成测试工程师的理想选择。
典型配置
                       L7104     B Switch, SP4T, dc-20 GHz, terminated （L-SERIES）
·                                                                                                                                                                                    L7104B-100 Solder terminals
·                                                                                                                                                                                    L7104B-024 24 VDC
·                                                                                                                                                                                    L7104B-T24 24 VDC bias with TTL logic
·                                                                                                                                                                                    L7104A-161 16-pin DIP socket and connector with 24 inch ribbon cable



产品
配置
寿命
重复性
隔离度
性能特性
L7104C
SP4T, terminated
2 million
0.03 dB
90 dB at 12 GHz
Position indicator, internal control logic, magnetic latching
L7204C
SP4T, unterminated
2 million
0.03 dB
90 dB at 12 GHz
Position indicator, internal control logic, magnetic latching
L7106C
SP6T, terminated
2 million
0.03 dB
90 dB at 12 GHz
Position indicator, internal control logic
L7206C
SP6T, unterminated
2 million
0.03 dB
90 dB at 12 GHz
Position indicator, internal control logic, magnetic latching


L7104C Multiport Coaxial Switch, DC to 26.5 GHz, SP4T
L7204C Multiport Coaxial Switch, DC to 26.5 GHz, SP4T
L7106C Multiport Coaxial Switch, DC to 26.5 GHz, SP6T
L7206C Multiport Coaxial Switch, DC to 26.5 GHz, SP6T
主要技术指标
特点
·                                                                                                                                                                                                   SP4T/SP6T 配置, 有负载端/无负载端
·                                                                                                                                                                                                   电子位置指示
·                                                                                                                                                                                                   电流中断能力
·                                                                                                                                                                                                   磁锁存
超级RF性能
·                                                                                                                                                                                                   无与伦比的隔离度, 典型 90 dB at 12 GHz
·                                                                                                                                                                                                   保证0.03 dB 插损重复性
·                                                                                                                                                                                                   200万次寿命
安捷伦L7104/6C系列多端口开关提高了射频和微波信号传输以及测试应用的准确度。其经济性价格的机电开关具有无可匹敌的隔离度和仅0.03dB插入耗损重复性,使用寿命达两百万次。L7104/6C系列的极低重复插损减少了测量中的随机误差源，因此提高了测量精度。这些开关的重复性和可靠性使得测量准确性得以保证,减少了校准周期、增加了测试系统的正常运行时间，从而降低了企业成本。安捷伦严密的设计制造规格成就了L7104/6C的高重复开关性能。

安捷伦L7104/6C系列多端口开关不仅在信号监测和输入应用方面性能优越，而且价格经济，是系统集成测试工程师的理想选择。

典型配置
                          L7104      C Switch, SP4T, DC-26.5 GHz, terminated （L-SERIES）
·                                                                                                                                                                                    L7104C-100 Solder terminals
·                                          &a, mp;n, bsp;                                                                                                                                         L7104C-024 24 VDC
·                                                                                                                                                                                    L7104C-T24 24 VDC bias with TTL logic
·                                                                                                                                                                                    L7104C-161 16-pin DIP socket and connector with 24 inch ribbon cable
