7248 Tronex Fine Hard Wire Cutters钳子

These cutters are made entirely from a solid alloy of tungsten, cobalt, chromium and vanadium to have cutting edges that are very sharp and very hard. The cutting edges are hardened by a special heat-treating process to a hardness exceeding 67 on the Rockwell C scale. The hardness of the edges extends to a significant case depth. The razor-sharp edges cut hard wire in stainless steel, nickel, Nitinol （nickel and titanium）, and tungsten as fine as 0.025mm （0.001"）. Generally, the maximum wire diameter is 0.20mm （0.008"）. Precision cutting of very fine wire is achieved with Tronex cutters through an especially fine joint design. The joint incorporates a hardened screw/nut combination, matched bearing rings and a delrin washer. They cut flush, leaving ends smooth and free of burrs and feature stainless steel springs, cushion grips and an anti-dulling protection device.

*Steel wire diameter cutting capacity

这些刀具完全由钨，钴，铬和钒的固体合金制成，切削刃非常锋利且非常坚硬。 切削刃通过特殊的热处理工艺硬化，在Rockwell C级别上硬度超过67。 边缘的硬度延伸到显着的表面深度。 锋利的锋利边缘切割不锈钢，镍，镍钛诺（镍和钛）和钨丝的硬线，精细到0.025mm（0.001“）。通常，线径为0.20mm（0.008”）。 Tronex刀具通过特别精细的接头设计实现了精细切割非常细的线材。 接头采用硬化螺钉/螺母组合，配套轴承套圈和delrin垫圈。 它们可以切割齐平，使端部光滑无毛刺，并配有不锈钢弹簧，缓冲夹具和防眩光保护装置。

*钢丝直径切割能力

Prod #

Description

Unit

7248

Fine Hard Wire Cutter, Miniature Oval, Semi-Flush, Short Handle, 0.20mm - 0.33mm （.008" - .013"）*

each

7250

Fine Hard Wire Cutter, Miniature Oval, Flush, Short Handle, 0.08mm - 0.25mm （.003" - .010"）*

each

50° Thin Taper, Short Handle, Class W

50° Taper Flush, Overall Length 117mm （4.6"）
