产品特性
1微电脑控制，触摸面板，LCD、LED双显示，运行参数可自动记忆，可RCF直接启动，方便操作使用
Microprocessor control, operated by touch panel, visual digital display, operated data can automatic memory, RCF value can be set directly for working and convenient use./convenient operation.
2大力矩无刷变频电机驱动，欧洲进口超高速轴承,运行平稳，免维护
Brushless converter motor which has high torque, imported super speed bearing from Europe, smooth running and maintenance free.
3多层减振结构，振动小、噪声低，环保
Multi-storey damping system, the compressor imported from Europe operating without Freon, it is running with low noise and slight vibration and green/environment protection.
4钢制机身，不锈钢离心腔，关键件进口，易清洁，耐用
Behch-top model and steel body, stainless steel centrifugal chamber, key components are imported, easy to clean and durable.
5转子识别系统，超温、超速、门盖、不平衡等保护功能，主机及转子寿命计算功能，确保安全
Automatic rotor identification prevents the rotor from overspeeding. overtemperature, door interlock, strap broken protection. The function of service life calculation, ensure safety.
6专有的气流导向设计，温升小；专有的SCT转速控制技术，升降速快，省时GX
Special air current disign, the temperature of centrifuge chamber is stable. particular SBT speed control design,the function of fast acceleration and deceleration, save time and best effects.
7、0-9档10种升降速率选择或直接输入升降速时间，可存储40种自定义工作模式，实现优化离心
Adjustable rise-and-decrease speed from grade 0 to 9 or directly set the time of acceleration and deceleration, and can be store 40 kinds of self-defining operating models to achieve the best results.
既能高速离心又能带水平转子低速离心通用性强
Multifunctional, centrifuging both high speed and low speed with large capacity swing rotor.
9、点动功能,短暂离心，便于多样化离心
Hold-on and transient centrifuging.
技术参数 TECHNICAL PARAMETE
型号 Model |
TG18G-Ⅱ |
Z高转速 Max Speed |
18000r/min |
Z大相对离心力 Max RCF |
21500×g |
Z大容量 Max Capacity |
2000ml |
转速精度 Speed Accuracy |
±20r/min |
定时范围 Time Range |
0-99h99min |
电源 Power Supply |
AC 220V 50Hz 18A |
整机噪声 Noise |
≤65dB |
外形尺寸 Dimension |
460×590×420mm |
重量 Weight |
48kg |
TG18G-Ⅱ转子Rotor
转子类型Model |
转子号
Number |
容量
Capacity |
Z高转速
Max Speed |
Z大离心力Max RCF |
试管尺寸（mm）
Dimension of tube |
角转子
Angle Rotor |
No.7 |
12×1.5ml |
18000 r/min |
21500×g |
Φ10×42 |
No.7 |
18×0.5ml |
18000 r/min |
21500×g |
Φ8×32 |
No.14 |
24×1.5/2.0ml |
15000 r/min |
21000×g |
Φ10×42 |
No.12 |
10×5ml |
16000 r/min |
17420×g |
Φ14×54 |
No.16 |
12×10ml |
15000 r/min |
23120×g |
Φ16×81 |
No.22 |
6×50ml |
13000 r/min |
17380×g |
Φ28×105 |
No.31 |
4×100ml |
10000 r/min |
9690×g |
Φ38×124 |
酶标转子Bucket Rotor |
No.44 |
2×48Holes |
3000 r/min |
1400×g |
酶标板子
Bucket Rotor |
水平转子Swing Rotor |
No.63 |
4×50/100ml |
5000 r/min |
4390×g |
Φ38×124 |
No.69 |
4×500ml
( 12×50ml/8×100ml) |
4000 r/min |
3580×g |
Φ80×140 |
No.70 |
4×250ml
(8×50ml/32×10ml) |
4000 r/min |
3500×g |
Φ64×113 |
No.77 |
32×10/15ml |
4000 r/min |
2810×g |
Φ16×85-118 |
No.81 |
8×50ml |
4000 r/min |
2810×g |
Φ28×105-115 |
No.82 |
48×5ml |
4000 r/min |
2800×g |
Φ14×54 |
No.84 |
148×7ml |
4000 r/min |
3080×g |
Φ13×78 |
