ZY6016加热变形试验机
Heat deformation testing machine
本机用来测试塑料及电线皮等材料的热变形程度。特定温度下，将试件于试验机内自由置放30分钟后，再夹在本机平行板间，加规定之荷重，同温度再置放30分钟，用量表量取其加热前后之厚度差，该厚度差除以加热前厚度，即为变形率。符合UL1581、GB2099标准
This machine is used to test the plastic and the thermal deformation of the wire material such as leather. Under certain temperature, the specimen in the testing machine free placed within 30 minutes, and then sandwiched between the machine between parallel plates, and of the load, implantation with temperature for 30 minutes, with a scale measuring the thickness difference of before and after heating, the thickness difference divided by the thickness, before heating is the deformation rate. UL1581, GB2099 standard
试验装置：3组
温度：常温~300℃
砝码：50、100、200、500、1000g各三个
量表：日本MITOTOYO 0.01/10mm
体积：内箱尺寸：长600mm*深400mm*高360mm
外箱尺寸：长1100mm*宽620mm*高1730mm
内箱材质：SUS#304不锈钢。
外箱材质：1.5mm钢板,采用静电烤漆
保温材质：高密度石棉
重量：113kg
Test unit: 3 groups
Temperature: room temperature to 300 ℃
Jordan farmar: 50, 100, 200, 500, 1000 g each three
Scale: Japan MITOTOYO 0.01/10 mm
Size: inner carton size: 600 mm * 400 mm * 360 mm high
Carton size: 1100 mm * 620 mm * 620 mm wide
In case material: SUS# 304 stainless steel.
Material: in the case of 1.5 mm steel plate, adopting electrostatic painting
Thermal insulation material: high density of asbestos
Weight: 113 kg
联系方式：东莞中诺（台湾）质检仪器设备有限公司
Contact: dongguan (Taiwan) quality inspection instrument equipment co., LTD
