GENERAL SPECIFICATIONS
GAS FILLING Ne +Halogen
CATHODE MATERIAL 446 Stainless Steel
MAXIMUM LENGTH (INCH/MM) 1.85/47.0
EFFECTIVE LENGTH (INCH/MM) 1.10/27.9
MAXIMUM DIAMETER (INCH/MM) 0.31/7.9
EFFECTIVE DIAMETER (INCH/MM) 0.306/7.77
CONNECTOR Pin
OPERATING TEMPERATURE RANGE °C -10 to +75
ELECTRICAL SPECIFICATIONS
RECOMMENDED ANODE RESISTOR (MEG OHM) 4.7
MINIMUM ANODE RESISTOR (MEG OHM) 2.2
RECOMMENDED OPERATING VOLTAGE (VOLTS) 500
OPERATING VOLTAGE RANGE (VOLTS) 450 - 650
MAXIMUM PLATEAU SLOPE (%/100 VOLTS) 8
MINIMUM DEAD TIME (MICRO SEC) 45
GAMMA SENSITIVITY CO60 (CPS/MR/HR) 7.5
TUBE CAPACITANCE (PF) 3
WEIGHT (GRAMS)
MAXIMUM BACKGROUND SHIELDED 50MM PB + 3MM AL (CPM) 4
WALL SPECIFICATIONS
AREAL DENSITY (MG/CM²) 30
THICKNESS (INCH/MM) 0.002/0.05
