商品简介：The Tektronix TDS784D is a high bandwidth, high resolution digitizing oscilloscope. It features 29 automatic measurements with measurement statistics and has a timebase accuracy of 25 ppm. The unit also provides wide dynamic range, flat response, fast overdrive recovery, calibrated DC offset, 1 mV/div sensitivity, 1 ns peak detect and internal calibration.
Frequency/Bandwidth: DC to 1GHz
Verticle Sensitivity: 1mV/div to 10V/div
Channels: 4
Sample Rate: 4 GSa/s (1 Channel)
Sweep Speed: 10s/div to 500ps/div
Display: Color
Interface: GPIB, RS - 232C, Centronics
Input Connectors: BNC Female
Input Impedance: 1megaohm to 50ohms
100/240VAC, 45 - 440Hz Operation
