尼康NIKON物镜CF Plan 100X

产品信息



加工定制：否 品Pai：NIKON/尼康 型号：CF Plan 100X
类型：物镜


深圳市磊佳贸易有限公司代理销售日本NIKON尼康显微镜物镜CF Plan100x/0.95 OFN25 WD 0.3

  • /0 Epi
  • Suitable for Non-Contact Optical Profiling
  • Michelson (2.5X and 5X) and Mirau (10X, 20X and 50X) Objectives Available
  • Infinity Corrected 200mm Tube Lens Design

Interferometry objectives are used in non-contact optical profile measurement devices to obtain surface maps and surface measurement parameters. They can be used to examine surface topography with very high precision—to within a fraction of the wavelength of light. In these objectives, a light beam passes through a beamsplitter, which directs the light to both the surface of the sample and a built-in reference mirror. The light reflected from these surfaces recombines and a fringe interference pattern is formed. The Michelson objectives provide comparatively longer working distances, wider fields of view and larger depth of focus, whereas the Mirau objectives are used in applications requiring higher magnification and/or numerical apertures. Use of the Nikon 200mm tube lens (#58- 520) allows these objectives to be integrated to a C-Mount camera.



Magnification 2.5X 5X 10X 20X 50X 100x
Numerical Aperture 0.075 0.13 0.30 0.40 0.55 0.7
Working Distance 10.3mm 9.3mm 7.4mm 4.7mm 3.4mm 2mm
Focal Length 80.0mm 40.0mm 20.0mm 10.0mm 4.0mm 2mm
Resolving Power 3.7µm 2.1µm 0.92µm 0.69µm 0.50µm 0.40µm
Depth of Focus 48.6µm 416.2µm 3.04µm 1.71µm 0.90µm 0.56µm
Field of View
Eyepiece, 25 Diameter Field 10.0mm 5.0mm 2.5mm 1.25mm 0.50mm 0.25mm
Eyepiece, 20 Diameter Field 4.4mm 2.2mm 2mm 1mm 0.22mm 0.2mm
2/3" Sensor Camera (H x V) 3.52 x 2.64mm 1.76 x 1.32mm 0.88 x 0.66mm 0.44 x 0.33mm 0.18 x 0.13mm 0.011 x 0.08mm
1/2" Sensor Camera (H x V) 2.56 x 1.92mm 1.28 x 0.96mm 0.64 x 0.48mm 0.32 x 0.24mm 0.13 x 0.10mm 0.08 x 0.06mm
Weight 440g 280g 125g 130g 150g 200g



商品名称

2.5X Nikon CF IC Epi Plan TI Interferometry Objective

5X Nikon CF IC Epi Plan TI Interferometry Objective

10X Nikon CF IC Epi Plan DI Interferometry Objective

20X Nikon CF IC Epi Plan DI Interferometry Objective

50X NIKON CF IC Epi Plan DI Interferometry Objective

100X Nikon CF IC Epi Plan DI Interferometry Objective





欢迎来电或在线咨询！咨询电话：400-657-0705    手机：13242449659  QQ：842471885   旺旺：wuyulunbi758
