OXYGOLD B 溶氧(DO)电极
- 品牌：瑞士汉密尔顿
- 型号：啤酒发酵溶氧电极,高温Do电极
- 产地：进口
- 供应商：北京恩耐德科技有限公司
- 标签：OXYGOLD B 溶氧(DO)电极, 货号：, 瑞士汉密尔顿, 啤酒发酵溶氧电极,高温Do电极, 北京恩耐德科技有限公司,OXYGOLD B 溶氧(DO)电极报价/价格,销售，使用，原理，操作，说明书，资料下载，促销，技术参数，维修，保修，售后服务，代理商，经销商，技术支持，进口/国产，用途
产品库
OXYGOLD B 溶氧(DO)电极
HAMILTON发酵溶氧电极、发酵DO电极、哈米尔顿发酵溶氧电极、高温DO电极、
HAMILTON发酵电极，哈米尔顿发酵电极，HAMILTON高温电极，哈米尔顿高温电极
哈米尔顿溶氧电极，HAMILTON发酵溶氧电极|发酵用DO电极OXYGOLD B
汉米尔顿溶氧电极，HAMILTON发酵溶氧电极|发酵用DO电极OXYGOLD B
夏米顿溶氧电极，HAMILTON微生物发酵电极|微生物发酵用OXYGOLD B
氧气：8ppb-饱和，
0.1%-200%
0-100度下，ZD压为12bar
温补：22k欧姆 ntc
●广泛用于酿造、可乐、果汁、汽酒和特殊化学过程
●压力和cip稳定
●用户可替换内部部件
●漂移小
●市场上从空气到纯净co2最短反应时
间：t98％<60秒。
●材料和检查证明
●轴
型号： 订购号：
oxygold b 120 237 180
plus oxylyte b 237 138
oxygold b 225 237 185
plus oxylyte b 237 138
附件：
oxylyte membrane-kit 237 136
oxylyte b 50 ml 237 138
polarization module b 237 360
replacement cathode oxygold b 237 437
各种护套
连接线
OXYGOLD B Oxygen Sensor OXYGOLD B Ordering Information
Dissolved Oxygen sensor for measurements in media containing acidic gases like CO2, e.g.beer
8 ppb to saturation or 0.08% to 200% of air oxygen
0 to 100°C
Max 12 bar
TC: 22kOhm NTC
Absolutely no cross-sensitivity to CO2
Developed for use in brewing, Cola, fruit-juice, sparkling wine and special chemical processes
Pressure and CIP stable
Easy to maintain
Inner body (anode, cathode assembly) can be replaced by user
No cooling or bypass required
Shortest response time from air to pure CO2: T98% <60 seconds
Supplied with materials and inspection certificate
Works cleanly with the same polarization voltages in calibration and measurement operation. You don't get the usual false measurement values when measuring dissolved oxygen in beer or the like
12 mm shaft and IP 68 VP connector head
Part #
Description
Shaft Length
237180
OXYGOLD B 120
120 mm
237185
OXYGOLD B 225
225mm
237360
Polarization Module B
237138
Oxylyte B Electrolyte 50ml
237135
OXYGOLD Membrane Kit (includes 3 membranes)
