美国harvardKDS 微量注射泵
中文产品详细介绍：
kds200可同时夹持两个注射器，容量10ul到140ml
具有注射驱动锁定/开启钮，防止误操作
菜单方式进行设置，操作简单
注射容量实时显示，完成设定值后自动停止
注射容量和速率单位可以根据需要进行选择
参数可以在注射时进行查看或进行更改
参数设置自动保存，下次开机时不需要再输入
自动检测停止状态
内置RS232接口，可以通过串口进行计算机控制100个微量注射泵
TTL接口进行计时、工作状态等控制
可配置编程功能，按键输入控制程序，注射时间和速率可调，并可以在12个小时内设置8个Step，每个Step
英文产品详细介绍：Two-Syringe Infusion Pump. This feature-laden two-syringe infusion pump combines a broad speed range and holds a wide range of syringe sizes to meet the requirements of virtually any laboratory application.
Features
l Holds one or two syringes, 10 µl to 140 ml each
l Backlit LCD display
l Knob locks/unlocks drive block for effortless, drag-free manual adjustment
l Simple menu-driven setup:
l select syringe size from displayed table
l dispense volume
l dispense flow rate
l Continuous dispense volume display
l Preset volume control and automatic shut-off
l Choice of unit selection
l Settings can be reviewed or changed during operation
l Stall detection
l Last settings stored in permanent memory
l Built-in RS232C interface for computer "daisy chaining" up to 100 pumps
l TTL interface for foot switch, timer, relay control, outputs for run indicator, valve control
l Optional multi-step keypad programmable feature (KDS200P)
Specifications |
Pump Type: |
Infusion |
Max. No. of Syringes |
Two |
Syringe Size |
10 µl to 140 ml |
Dimensions |
§ 11 x 9 x 5.5 in.
28 x 23 x 15 cm |
Weight |
9 lb (4 kg) |
Linear Force |
40 lb (18 kg) |
Advance Per Microstep |
0.165 micron (1/16 step) |
Max Step Rate (1/2 Step) |
1600/sec |
Min Step Rate |
1 step 1/100 sec |
Accuracy |
± < 1% |
Reproducibility |
± 0.1% |
Audible Alarm |
(Optional) ** |
