| 是否提供加工定制 | 是 | 类型 | 视频显微镜 |
| 品Pai | 微林光学 | 型号 | XDS-M0745FI |
| 仪器放大倍数 | 0.7x-4.5x | 目镜放大倍数 | 0.35x,0.5x,0.75x,1x,2x |
| 物镜放大倍数 | 0.7-4.5x | 重量 | 450（g） |
| 适用范围 | 微电子 LCD | 装箱数 | 10PCS/box |
| 规格 | 10PCS/box | | |
XDS-M0745series mini Lensare a monocular continuous zooming Lens, using with the high definition colour CCD or CMOS camera & TV or LCD together. Having long working distance, wide field of view; fine definition image. According to the different requirement in different condition, the user can select the supplementary objective: 0.3×,0.5×,0.75×,1.5×,2×and CCD adapter: 0.35×,0.5×,0.75×,1.5×,2×. There are also several kinds of illumination: double illumination(XDS-10C inclined light in halogen bulb, transmitted light in fluorescent),ring fluorescent illumination, or fiber optics light. It also can use with the image data analyzing system. The stand has: pillar(XDS-10A,10B,10C),and universal stand(XDS-10US1).Technical Specifications:Zoom Range of the Lens Body:0.7x -4.5xZoom Rate:6.5:1Working distance:W.D.95mm, holder diameterΦ28mm,Focus Fine:any position focus of C/CS MountIris Adj:high definition and high depth of focusStandard optional:0.5X CCD Adapter (Lens Body length:L160mm)Out size: 200*300*150mmNetweight:0.45Kg/pcsGrossweight:5kg/10pcsOptional:CCD Adapter: 0.35X/L143mm,0.75X/L206mm,1X/L246mm,1.5X/L271mm,2X/L295mmAuxiliary Lenses:0.3X/W.D.320mm,0.5X/W.D.180mm,0.75X/W.D.105mm,1X/W.D.95mm,1.5X/W.D.46mm,2X/W.D.32mmopticalmagnification:0.07X-18XFOV:0.33-81.6mmTotal magnification:4.3X-1065X(1/3"CCD,14”monitor)
