MD90 usb数码显微镜摄像头 MD90 数码显微镜摄像头
- 产地：广东 广州市
- 供应商：广州市明美科技有限公司
- 供应商报价： 10400.00￥/台
- 标签：usb数码显微镜摄像头 MD90 数码显微镜摄像头,usb数码显微镜摄像头 MD90 数码显微镜摄像头价格,usb数码显微镜摄像头 MD90 数码显微镜摄像头厂家
产品信息
| 是否提供加工定制 | 是 | 类型 | 显微镜摄像头 |
| 品Pai | MSHOT | 型号 | MD90 |
| 仪器放大倍数 | 10 | 目镜放大倍数 | 10 |
| 物镜放大倍数 | 10 | 重量 | 120（g） |
| 适用范围 | 显微镜专用摄像头 | 装箱数 | 1 |
MSHOT®MD90is a feature-packed, high-resolution digital microscope camera, spectacular high-resolution image capturing, unmatched image database software ,using standard USB2.0 interface means smooth, live color preview on the computer display True plug-and-play camera allows installation in minutes! MSHOT®MD90 can be widely used in industrial management, teachingand research, materials analysis, clinical testing, and so on.Feature■as high as 9 megapixel, providing excellent high-quality and high-resolution images■Standard C-Mount makes connection to any standard trinocular microscope, such as stereo zoom microscope, metallography microscope; Biomicroscopy Macro lens setups are also supported!■Easy-to-operate with strong compatibility operating software, True plug-and-play camera allows to work in minutes■Supporting for video functions, easy to preserve and transfer■Superb color rendition with auto and manual white balance controls.Specification:
Item | Specification | Item | Specification |
sensor | 1/ 2.3〞CMOS | Sensitivity | 0.44 V/lux-sec (550nm) |
Resolution | 3488x261Effective Pixels | Cable | USB2.0 (480 Mbit / sec) |
Pixel size | 1.75μm x 1.75μm | Power | DC 5V ± 5% |
Frame rate | 9fps @ 3488 x 2616 | Electricity | ≈200 mA |
30 fps @ 640 x 480 | White balance | Manual/Auto |
Shutter | Electronic | Exposure control | 10μs–32ms,Auto exposure |
S/N ratio | 40.5 dB | Software | Display/Film/Video |
Scan mode | Progressive scanning | Operating Tem | -30°C~ 70°C |
