CPX400SA CPX400SA英国tti电源

产品信息
CPX400SA英国tti电源,CPX400SA价格： CPX400SA
Bench/System DC Power Supply, PowerFlex Regulation, Smart Analog Controls Single Output, 60V/20A 420W, Isolated Analogue Interface
 High power single output


The CPX400S is a single output version of the best selling CPX400D.


The ultra-compact design (quarter rack 3U) takes up minimum space for bench or system use.


PowerFlex regulation enables the 420 watts of power to be configured to suit each specific application.  See the power curve below for more information


Three versions are available, manual control only (S), with isolated analog remote control (SA), or with digital remote control via USB, RS232, GPIB and LAN (SP).

CPX400SA英国tti电源,CPX400SA价格：
PowerFlex design gives variable voltage and current combinations within a maximum power range
Up to 60 volts and up to 20 amps
180 watts or 420 watts maximum per output
Isolated outputs can be wired in series or parallel
Constant voltage or constant current operation
Settings Locking (S-Lock)
PowerFlex or fixed-range operation
Variable OVP trips
Selectable remote sense terminals
Compact quarter or half rack 3U case size
Isolated analogue remote control (CPX400SA only)
RS232, USB, GPIB & LXI compliant LAN (P models only)





CPX400SA英国tti电源,CPX400SA价格：
Compact design


The CPX series achieves an unusually high power density for a dual output power supply offering up to 840 watts from a case just 212mm wide (half rack, 3U).


This gives it a small bench footprint taking up less space on a crowded bench.


For rack-mount application, up to two units can be mounted into a single 3U slot.


Overall dimensions are just 212mm wide x 130mm high x 375mm deep.


The single output supply is half that width enabling up to four units to be mounted within one rack width.


Overall dimensions are just 107mm wide x 130mm high x 398mm deep.
