TG330英国tti信号源,Aim-tti TG330价格 TG330英国tti信号源,Aim-tti TG330价格

TG330英国tti函数信号源,Aim-tti TG330价格： TG330
3MHz Analog Function Generator with LCD readout 3MHz Generator, Counter, Sweep, AM0.03Hz to 3MHz frequency range
Simultaneous display of frequency & amplitude
External seven digit 120MHz counter (not TG315)
High waveform quality at all frequencies & levels
2mV to 20V pk-pk from 50 Ohms or 600 Ohms
Variable symmetry with constant frequency
Auxiliary TTL/CMOS output
1000:1 frequency change by vernier or sweep voltage
Precision internal lin/log sweep (TG330 only)
Internal/external AM up to (TG330 only)TG330英国tti函数信号源,Aim-tti TG330价格：
Frequency Range: 0.03Hz to 3MHz in 7 overlapping decade  ranges with fine adjustment by a vernier.
Vernier Range: 1000:1 on each range.
Distortion: <0.5% on 300, 3k and 30k ranges; <1% on  3, 30 and 300k ranges; all harmonics >25dB  below fundamental on 3M range.
Amplitude Flatness: ±0.2dB to 200kHz; ±2dB to 3MHz.
TRIANGLE  Linearity: Better than 99% to 200kHz  SQUARE WAVE  Rise/Fall Times: <100ns  Mark - Space Ratio: 1:1 ± 1% to 100kHz  DC
Range: ±10V unterminated
SYMMETRY
Symmetry Range: Variable typically 1:9 to 9:1 (on top decade of  each range), frequency divided by 10.
