箱式气氛炉Atmosphere furnace  箱式电炉 气氛炉
      本系列电炉可以通入堕性气体使高温加热工件不会产生氧化脱碳，本电炉适合其他需要各种气体保护的高温烧结，淬火等热处理工艺。按国家机械行业JB4311.7-91标准为基础，电炉具有LTDE可编程控制系统，电炉外壳采用优质冷板及型钢制作，外壳高温喷塑，电炉背面和正面采用特定制作工艺具有进气和出气装置,独特的堕性气体预加热功能，避免堕性气体的低温与电炉内高温产生温度冲击。This series of electric furnace can pass into the inert gas in the high temperature heating the workpiece does not produce oxidation and decarbonization, the electric furnace for sintering of other gases is the protection of and quenching heat treatment process. According to national machinery industry JB4311.7-91 standard is based, the furnace has ltde programmable control system, furnace shell using high-quality cold plate and steel making, shell with plastic sprayed high temperature, furnace back and face the specific production process is provided with an air inlet and an air outlet device, Inert gas pre heating function unique,to avoid shock temperature  the furnace is in high temperature shock.。

产品型号QFXL系列 DAOHAN	1000℃气氛电炉 1000℃Atmosphere furnace
	QFXL- 0810
额定功率Power（KW)	8
额定电压Voltage	380V
相数Phase number	3
极限温度Limit temperature	1000℃
使用温度Use temperature	RT+100-900℃
加热件接法Heating method	△
升温速率Heating time	≤10℃/min；（可任意调节低于每分钟10度的任何速度）
测温元件Temperature measuring element	K型热电偶K type thermocouple
控温精度 control accuracy	±1℃
空炉损耗Furnace air loss	< 1.2
积蓄热Heat savings	< 8
炉温均匀度Temperature uniformity	< 15
炉膛尺寸Size of furnace	400×250×160
外型尺寸Size	800×520×587
净重Net weight	118
备注:特殊规格和技术要求，DAOHAN®公司可以根据客户需求来定制。欢迎来电来函。Such as special technical requirements, can be customized.
