HY329FH-W 厂家直销HY329FH-W锅炉水泵温控器

是否提供加工定制	是	品Pai	华阳天地
型号	HY329FH-W	控制类型	温度
控制模式	智能温度控制调节器	测量对象	电锅炉 循环泵
温度范围	0-95（℃）	测温误差	1（℃）
开孔尺寸	1（mm）	安装型式	标准86盒安装
输出信号	2（mA）	工作电压	AC220（V）
外形尺寸	86*86*13（mm）	重量	0.22（Kg）

HY329FH-W智能电采暖炉温控器适用于工业、商业及家庭居室中电采暖炉系统的温度控制。温控器采用微电脑控制技术，大液晶屏显示。特有的高温保护功能，在检测水温的同时又增加了对采暖设备的温度监测，四时段编程控制功能，可以根据人的生活习惯，分时段设定不同的环境温度，真正实现舒适、节能。主要功能：1、大屏幕液晶显示2、北京时间功能 3、智能编程功能（每周7天，每天4时段的温度设置）4、掉电记忆功能5、防冻保护功能6、蓝色背光功能（选配） 7、高温保护功能（选配） 8、漏电保护功能9、三档功率输出功能 10、循环水泵控制功能技术参数：电源电压：AC220设定温度范围：0-95℃控温精度：±1℃加热负载：三组,每组<2,水泵负载：<3A 自身功耗：1W显示：LCD外壳：高级阻燃ABS材料外型尺寸：86X86X13mm安装孔距：60mm（标准） 可根据用户要求，灵活设计！HY329FH-W Smart electric stove temperature control for industrial, commercial and family room, electric heating stove in the temperature control system.Thermostat microcomputer control technology, large LCD screen display.Unique high-temperature protection, in the detection of water temperature and increase the heating device for temperature monitoring, four-time programming control function, according to people's living habits, different time periods set different temperature, the real comfort, energy saving.Main features:1, large-screen liquid crystal display2, Beijing Time function3, intelligent programming (7 days a week, 4 hours a day temperature settings)4, power-down memory function5, antifreeze protection6, the blue backlight (optional)7, high temperature protection (optional)8, leakage protection9, third gear power output10, circulating pump controlTechnical parameters:Power supply voltage: AC220Setting temperature range: 0-95 ℃Temperature accuracy: ± 1 ℃Heating load: three groups of <2,Pump Load: <3ATheir power consumption: 1WDisplay: LCDHousing: High flame retardant ABS materialDimensions: 86 X 86 X 13mmInstallation hole distance: 60mm (standard)According to user requirements, design flexibility!HY329FH-W Smart electric stove temperature control for industrial, commercial and family room, electric heating stove in the temperature control system.Thermostat microcomputer control technology, large LCD screen display.Unique high-temperature protection, in the detection of water temperature and increase the heating device for temperature monitoring, four-time programming control function, according to people's living habits, different time periods set different temperature, the real comfort, energy saving.Main features:1, large-screen liquid crystal display2, Beijing Time function3, intelligent programming (7 days a week, 4 hours a day temperature settings)4, power-down memory function5, antifreeze protection6, the blue backlight (optional)7, high temperature protection (optional)8, leakage protection9, third gear power output10, circulating pump controlTechnical parameters:Power supply voltage: AC220Setting temperature range: 0-95 ℃Temperature accuracy: ± 1 ℃Heating load: three groups of <2,Pump Load: <3ATheir power consumption: 1WDisplay: LCDHousing: High flame retardant ABS materialDimensions: 86 X 86 X 13mmInstallation hole distance: 60mm (standard)According to user requirements, design flexibility!
