PAROX1200 磁氧O2传感器、顺磁氧分析仪

技术数据               PAROX1200U           PAROX1200H

                     非加热单元不带补偿       加热单元带温度补偿

zui小测量范围             0-5%VOL                         0-5%VOL

zui大测量范围             0-100%VOL                      0-100%VOL

电源供应                 5VDC-28VDC                    12-28VDC

                        zui大1.5W                       zui大12W

输出                    0-1V或0-4V                     0-1V或0-4V

可选的输出              4-20mA或0-10V                 4-20mA或0-10V

电流隔离                 是                                是

响应时间                 ＜3s                             ＜3s

气体流速在150ml/min(T90)

zui大气体流速             300ml/min                        300ml/min

运行温度                 15-30℃                           0-45℃

                        0-60℃客户自己补偿

加热温度                                                    55℃

温度传感器             可选的                           内置的

线性                  ＜±0.1%O2                      ＜±0.1%O2

零点设定偏差          ＜±0.1%O2/每周                 ＜±0.1%O2/每周

重复性                 ＜－0.05%O2                     ＜－0.02%O2

温度偏差

零点漂移              ＜±0.1%O2/℃                   ＜±0.03%O2/℃

灵敏度漂移           ＜±0.1%测量值/℃                  ＜±0.1%测量值/℃

可选的项

流速控制             流速10-90L/H恒定流速通过测量单元大约100ml/min

固定通过式           流速18-70L/H

气体预热              -

气体连接头           管3mm或1/8inch 5mm内纹
