SFI-100 Dwyer SFI-100/300/350/360/400/700目视流量计

产品信息

Dwyer SFI-100/300/350/360/400/700目视流量计应用：冷却系统流量指示、润滑系统、供燃料系统等
100——单窗带叶轮
300——双窗带叶轮
350——双窗无叶轮指示
360——双窗带叶拍
400——管状无叶片指示
700——管状带叶片带内部擦拭器

选型表：

100和300系列特性
介质: 兼容液体或气体.
接液材质: 窗口: 回火玻璃; 本体: 紫铜或316 SS; 密封片: Buna-N, 氟橡胶or PTFE; 指示轮: ABS or 316 SS叶轮(100 and 300), 304 SS or 316 SS挡板(360).
温度限制: 200°F (93°C).
压力限制: 125 psig (8.62 bar), 150 psig (10.34 bar) on "MP" Models.
连接: 螺纹.

Dwyer SFI-100/300/350/360/400/700目视流量计

举例SFI300SS2G2SFI-300SS-2-G2 Sight Flow Indicator; double window, temper glass, Viton® gaskets, 316SS body, ABS impeller, 2 inch female NPT connections.
型号SFI    Sight flow indicator, tempered glass standard, Buna-N gaskets standard, female NPT connections standard.
类型 100
300
350
360		   Single window, bronze body, ABS Impeller
Double window, bronze body, ABS Impeller
Double window, bronze body, no moving indicator
Double window, bronze body, 304SS flapper
本体选项  SS
MP		  316SS body option for 300, 350, 360
150 psig maximum pressure option, includes Viton® gaskets
连接尺寸   1/4
3/8
1/2
3/4
1
1-1/4
1-1/2
2		 1/4 inch connection size
3/8 inch connection size
1/2 inch connection size
3/4 inch connection size
1 inch connection size
1-1/4 inch connection size
1-1/2 inch connection size
2 inch connection size
选项    W2
G1
G2
S2
S3
I1
I2
I3
F1
BSPT
BSPP		Plexiglass window
Teflon® gasket
Viton® gasket
316SS Shaft (Not on 350 Model)
Monel Shaft (Not on 350 Model)
ABS impeller with bronze bushing (Not on 350, 360)
316SS impeller (Not on 350, 360)
No impeller (100 only)
316SS Flapper (360 only)
BSPT threads
BSPP threads



300F系列特性
介质: 兼容液体或气体.
接液材质: 窗口: 回火玻璃; 本体: 碳钢或316 SS; 密封片: Buna-N, 氟橡胶or PTFE; 指示轮: ABS or 316 SS叶轮(360)
温度限制: 200°F (93°C).
压力限制: 150 psig (10.34 bar)
连接: 法兰

Dwyer SFI-100/300/350/360/400/700目视流量计

举例SFI360FSS1-1/2G1SFI-360FSS-1-1/2-G1 Sight Flow Indicator; double window, tempered glass, Teflon® gasket, 316SS body,304SS flapper, 1-1/2 inch raised face flange connections
型号SFI   Sight flow indicator, double window, tempered glass, Buna-N gaskets standard, raised face flange connections
类型 350FCS
350FSS
360FCS
360FSS		  Carbon steel body, no moving indicator
316SS body, no moving 316SS indicator
Carbon steel body, 316SS flapper
316SS body, 316SS flapper
连接尺寸  1-1/2
2
3
4
6		 1-1/2 inch raised face flange connection size
2 inch raised face flange connection size
3 inch raised face flange connection size
4 inch raised face flange connection size
6 inch raised face flange connection size
可选项   G1
G2		Teflon® gasket
Viton® gasket



400系列特性
介质: 兼容液体或气体.
接液材质: 筒子: 回火硼硅酸盐; 本体: 铸铁或316 SS; 密封片:PTFE
温度限制: 200°F (93°C).
压力限制: 50 psig (3.45 bar)
连接: 螺纹或法兰



举例SFI4001-1/2SFI-400SS-1-1/2 Sight Flow Indicator; tube type, borosilicate tube, Teflon® gaskets, 316SS body, 1-1/2 inch female NPT connections
型号SFI  Sight flow indicator, tube type, borosilicate tube, Teflon® gaskets
类型 400CI

400SS
400F
 		 Female NPT connections, cast iron body
(only for 1 through 2 inch sizes)
Female NPT connections, 316SS body
Raised face flange connection, 316SS body
(only for 1 inch and up sizes)
尺寸  1/2
3/4
1
1-1/4
1-1/2
2
3
4		1/2 inch connection size
3/4 inch connection size
1 inch connection size
1-1/4 inch connection size
1-1/2 inch connection size
2 inch connection size
3 inch connection size
4 inch connection size



700系列特性
介质: 兼容液体或气体.
接液材质: 筒子: 回火硼硅酸盐; 本体: 黄铜或316 SS; 密封片:氟橡胶; 指示轮: 乙缩醛
温度限制: 212°F (100°C).
压力限制: 230 psig (15.86 bar)
连接: 螺纹



举例SFI700SS1-1/2 SFI-700SS-1-1/2 Sight Flow Indicator; tube type with 8 blade Delrin® impeller and integral wipers to clean tube interior, tempered borosilicate tube, Viton® gaskets, 316SS body, 1-1/2 inch female NPT connections
型号SFI   Sight flow indicator, tube type with 8 blade Delrin impeller and integral wipers to clean tube interior, tempered borosilicate tube, Viton® gaskets
类型 700
700SS		  Brass body
316SS body
连接尺寸  1/4
3/8
1/2
3/4
1
1-1/4
1-1/2		 1/4 inch female NPT connection size
3/8 inch female NPT connection size
1/2 inch female NPT connection size
3/4 inch female NPT connection size
1 inch female NPT connection size
1-1/4 inch female NPT connection size
1-1/2 inch female NPT connection size
可选项   BSPT
BSPP		BSPT threads
BSPP threads
