TESA HITE 400/700 瑞士TESA一维测高仪数显高度仪

订货号

Order No.

描述

Description

规格和尺寸

Model and  Size

每台测高仪(含控制面板)包含下零组件

Each set  above with control panel consists of following components

00760143

标准测头安装座一个

1 Standard  insert holder

l

00760227

测球直径为5 mm的标准测头一只

1 Standard 5mm measuring probe

l

00760219

名义尺寸为6.35 mm的校验件一个

1 Master  piece with nominal size 6.35 mm

l

00760226

1 电子气浮

1 Electric pump for creating the air-cushion

l

00760157

6V可充电电池一个

6V rechargeable  battery

l

04761054

电源适配器一个, 110 ~ 240伏, 50 ~ 60 赫兹输入

1 Mains  adapter, 110 to 240 Vac/50 to 60 Hz

l

04761055

带欧式插头的电源线一根

1 Cable EU  for mains adapter

l

04761056

带美式插头的电源线一根

1 Cable US  for mains adapter

l

Model/  型号规格

TESA Hite

400/700

测量范围/ Measuring span

mm

415/715

应用范围/ Application range

配标准附件/ With standard accessory

配订货号00760057的测头座

配订货号S07001622的测头座

mm

570/870

625/925

795/1095

zui大允许误差(带标准附件)/ Max. permissible error, with standard accessory

(2.5+4L)μm,

(L单位为米/L  in m)

重复性(带标准附件)/ Repeatability, with standard accessory

平面:2μm  孔内: 3μm

zui大运动速度/Max. Displacement speed

500   mm/s

测量力/Measuring force

1.5N±0.5N

机械垂直度/ Mechanical  Perpendicularity

μm

9/13

主机重量/ Net weights, without panel  and battery pack

kg

27/32

充电一次使用时间/ Life time of the  rechargeable battery

60小时/ 60hours
