进口常压馏程仪

进口常压馏程仪的特点：
1)它是一款非常优秀的石油蒸馏仪，可用于汽油、燃料、油、溶剂、芳香烃、石脑油、石蜡油、碳氢物、和其他易挥发物，以用于严格的质量控制标准。它可自动操作、处理结果，按ASTM, ISO, DIN 或相关国际标准提供标准报告；
2)无氟制冷和加热系统可在蒸馏系统中快速转换；
3)当蒸馏完毕后，加热部分可快速冷却，以缩短下一次操作间隔时间；
4)专用软件可用于数据分析和仪器控制。蒸馏方法或参数可方便编写或修改；
5)GX的24VAC加热器可提供精确温度控制，以确保仪器蒸馏速率；
6)一套Pt-100 RTD温度探头，可监测蒸馏瓶蒸汽、冷凝器、接收瓶等温度，模仿水银温度计，精确度达±0.01℃；
7)进口常压馏程仪内置灭火系统和光学检测器，可快速反应，以确保操作者和实验安全；
8)完整的数据保存，电脑可控制；
9)软件可计算重复性和再现性，符合ASTM D86-04b，与标准品的标准和相对误差；
10)3025型提供内置电脑，触摸键盘、键盘、鼠标；
11)接收瓶的加热系统适合石蜡或其他在蒸馏时的固体物质；
12)软件使用方便，适合一般人员：
13)可外接电脑控制，可连续监测测试结果、仪器操作、安全特点、警示操作者维护等；
14)测试结果被实时显示，可提供蒸馏曲线和温度，带或不带气压补偿，或蒸馏校正，蒸发率，加热功率曲线，控制曲线补偿，快速功能用于加热和温度曲线的高分辨率曲线；
15)点对点的蒸馏结果比较，很方便用于质量控制和参考；
16)每个自动蒸馏仪都提供完整的仪器、配件，可标准执行ASTM D86和其他标准的0 ~ 4步蒸馏步骤。不须其他的配件。软件功能很方便操作。日常维护简单；
17)可自己定义操作程序；
18)可视觉或自动监测干点，符合ASTM D850、D1078方法。仪器已提供标准的干点分析方法，只须另外的配件如干点热电偶、200mL烧瓶，PTFE塞子以进行干点分析；
19)尺寸LWH: 53.3x54.6x70.5 cm, 净重91kg；
20)电源：230V, 50/60Hz, 10A；

 the result of more than
60-years experience in
developing distillation analyzers!
Model 40.10 special features:
  Automatic temperature calibration, (effected auto-
matically before each distillation run without need
of external calibration equipment)
  Level follower with stepper motor and
  Automatic calibration of the volume measurement,
zero point and/or 100 ml
  Low mass / low volt heating
  Accuracy: +/- 0,1 ml volume,
+/- 0,01°C temperature
  Level follower with cooling / heating system,
range 0 – 60°C
  Distillation range 0 – 450°C
  Calculation of cetane index
  100 and 200 ml measuring cylinders useable,
consequently 100 and 200 ml test samples may be
distilled
  ”door open“ sensor
  built in environment friendly Peltier elements for
cooling and heating
  built in automatic fire-extinguishing system for
connection to an external Nitrogen (N2) supply
Hg
Automatic Distillation
Apparatus Model 40.10
with installed microprocessor
control and integrated
MS-Windows 7 PC
NEW
  automatic-dry-point-detection-system for solvents,
including thermocouple, 200 ml flask, PTFE plug
and accessories
  Emergency ”STOP ALL” switch
  New, slim design
 Learning Program
  Built in, Windows based PC, with 10,4“ TFT active
colour LCD-Display with Touch-Screen for most
comfortable operation of the analyzer, including:
  – In Atom Micro-Processor
  – 16 GB compact flash card,
  – Ethernet interface for intranet connection,
  – USB plugs for possible connections of:
  – keyboard,
  – mouse / trackball,
  – printer.
  – Software package,
  – Windows Software.Technical changes reserved. © Copyright ESTANIT 2012
NEW Automatic Distillation Apparatus Model 40.10
with installed microprocessor control and integrated MS-Windows 7 PC
used for distillation products, solvents and crude oil in accordance the following standards:
ASTM D86 (group 0-4), ASTM D216, ASTM D285 (modified), ASTM D447, ASTM D1078
(internal standardized with solvents and group 7 and 8), IP 123, ISO 3405 and DIN 51751.
Multiple units may be linked on a central PC.
The units are programmed with all necessary distillation parameters. All units
can operate independently.
All relevant distillation data is stored on the built-in PC and can optionally be stored on a
network device, e.g. a server, NAS or dedicated storage device or USB devices.
Example of different distillations:
ASTM D86  group 0,1,2,3: Distillation of  hydrocarbon up to 300°C
  FBP,  e.g. all type of  petrol,  aviation, turbine fuel  etc.
ASTM D86  group 4: Distillation of diesel fuel, gas oil,
  furnace oil, heavy product etc, up to 450°C FBP.
ASTM D1078  group solvents. (visual - manual dry point-detection)
ASTM D1078  group solvents (automatic dry point detection)
ASTM D1078  group 7 and 8 (modified dry point detection)
ASTM D285  (modified), group 6: Distillation of crude oil

Main voltage:  110 ~ 235 V AC, 50 ~ 60 Hz, ± 10% (wide range input).
Operation voltage:   24 V DC.
Connecting cable:  approx. 2 m long.
Required power input:  approx. 2,0 kW
Recommended main fuse:  16 A lag
Dimensions approx.:  width 515 mm, depth 500 mm, height 670 mm
Weight:  approx. 56,0 kg
Ambient Temperature:  16°C ~ 32°C  (60°F ~ 90°F)
Humidity:  10 % – 65 %.
Each of our analyzers will be delivered with the following standard accessories
for immediay operation:
– Distillation flask 125 ml
– Distillation flask 200 ml
– Ceran plate with hole 32 mm [1]
– Ceran plate with hole 37,5 mm [1]
– Ceran plate with hole 50 mm [1]
– Resistance thermometer Pt 100 with cable and plug
– Special graduated receiver cylinder complete with metal base
– Wiper for condenser tube
– Instruction manual printed in English.
