CMP PX2KW/M矿用防铠装爆格兰（CMP PX2KW/M Cable Gland）
CMP PX2KW/M | Ex e, Ex d | Explosive Atmosphere Barrier Cable Gland
For all types of Steel & Aluminium Wire Armoured cables
上海颐品自动化科技有限公司，：
Mining, Internationally Approved, Explosive Atmosphere Barrier Cable Gland
• Metal-to-metal armour clamping
• Direct & remote installation
• Compound barrier type flameproof seal
• Controlled outer ‘load retention’ seal
• Unique OSTG prevents overtightening
• -60?C to +85?C
• Permitted in Zone 1
• Internationally marked, IECEx & ATEX
• EMC tested
Also available with RapidEx
CertificatesClick here to view Certificates
CLICK HERE TO VIEW TECHNICAL ILLUSTRATION
CLICK HERE TO VIEW HOW TO ORDER
Showing: Imperial Metric
| Cable Gland Size | Available Entry Threads "?C"? (Alternate Metric Thread Lengths Available) | Maximum Number Of Cores | Diameter Over Conductors "?A"? | Cable Bedding Diameter "?G"? | Overall Cable Diameter ?"B"? | Armour Range | Across Flats ?"D"? | Across Corners "?D"? | Protrusion Length "?F"? | Combined Ordering Reference (Brass Metric) | Shroud | Cable Gland Weight (Kgs) | ||||||||
| Standard | Option | |||||||||||||||||||
| Metric | Thread Length (Metric) ?"E"? | NPT | Thread Length (NPT) "?E"? | NPT | Min | Max | Min | Max | Max | Max | Size | Type | Ordering Suffix | |||||||
| 20S | M20 | 15.0 | 1/2?" | 19.9 | 3/4?" | 11 | 11.7 | 11.7 | 9.5 | 15.9 | 0.8 | 1.25 | 30.5 | 33.6 | 62.0 | 20S | PX2KW/M | 1RA | PVC06 | 0.230 |
| 20 | M20 | 15.0 | 1/2?" | 19.9 | 3/4?" | 11 | 12.6 | 12.9 | 12.5 | 20.9 | 0.8 | 1.25 | 30.5 | 33.6 | 63.0 | 20 | PX2KW/M | 1RA | PVC06 | 0.240 |
| 25S | M25 | 15.0 | 3/4?" | 20.2 | 1?" | 21 | 17.5 | 17.9 | 14.0 | 22.0 | 1.25 | 1.6 | 37.5 | 41.3 | 69.5 | 25S | PX2KW/M | 1RA | PVC09 | 0.370 |
| 25 | M25 | 15.0 | 3/4?" | 20.2 | 1?" | 21 | 17.5 | 17.9 | 18.2 | 26.2 | 1.25 | 1.6 | 37.5 | 41.3 | 69.5 | 25 | PX2KW/M | 1RA | PVC09 | 0.370 |
| 32 | M32 | 15.0 | 1?" | 25.0 | 1 1/4?" | 38 | 23.6 | 23.9 | 23.7 | 33.9 | 1.6 | 2.0 | 46.0 | 50.6 | 75.0 | 32 | PX2KW/M | 1RA | PVC11 | 0.570 |
| 40 | M40 | 15.0 | 1 1/4?" | 25.6 | 1 1/2?" | 59 | 30.0 | 30.3 | 27.9 | 40.4 | 1.6 | 2.0 | 55.0 | 60.5 | 75.0 | 40 | PX2KW/M | 1RA | PVC15 | 0.800 |
| 50S | M50 | 15.0 | 1 1/2?" | 26.1 | 2?" | 89 | 36.6 | 36.9 | 35.2 | 46.7 | 2.0 | 2.5 | 60.0 | 66.0 | 77.0 | 50S | PX2KW/M | 1RA | PVC18 | 0.900 |
| 50 | M50 | 15.0 | 2?" | 26.9 | 2 1/2?" | 89 | 41.0 | 41.3 | 40.4 | 53.0 | 2.0 | 2.5 | 70.1 | 77.1 | 77.0 | 50 | PX2KW/M | 1RA | PVC21 | 1.190 |
| 63S | M63 | 15.0 | 2?" | 26.9 | 2 1/2?" | 115 | 47.9 | 48.4 | 45.6 | 59.4 | 2.0 | 2.5 | 75.0 | 82.5 | 79.7 | 63S | PX2KW/M | 1RA | PVC23 | 1.390 |
| 63 | M63 | 15.0 | 2 1/2?" | 39.9 | 3?" | 115 | 53.7 | 54.0 | 54.6 | 65.8 | 2.0 | 2.5 | 80.0 | 88.0 | 80.3 | 63 | PX2KW/M | 1RA | PVC25 | 1.410 |
| 75S | M75 | 15.0 | 2 1/2?" | 39.9 | 3?" | 140 | 59.9 | 60.2 | 59.0 | 72.0 | 2.0 | 2.5 | 90.0 | 99.0 | 86.8 | 75S | PX2KW/M | 1RA | PVC28 | 2.090 |
| 75 | M75 | 15.0 | 3" | 41.5 | 3 1/2?" | 140 | 64.2 | 64.2 | 66.7 | 78.4 | 2.5 | 3.0 | 100.0 | 110.0 | 88.3 | 75 | PX2KW/M | 1RA | PVC30 | 2.540 |
| Dimensions are displayed in millimetres unless otherwise stated | ||||||||||||||||||||
