Environment
Ambient temperature
(operating and storage)
- 15 … + 60 °C (+ 5 … + 122 °F) for sensor-fitting in PVC
- 15 … + 80 °C (+ 5 … + 176 °F) for sensor-fitting in PP
- 15 … + 100 °C (+ 5 … + 212 °F) for sensor-fitting in stainless
steel, brass or PVDF
depending on associated transmitter
Standards, directives and Certifications
Directive - Pressure Complying with article 4, §1 of 2014/68/EU directive*
Certificate
on request
Inspection certificate 3.1 (acc. to EN-ISO 10204); Test report 2.2
(acc. to EN-ISO 10204); Certification of Conformity for the surface
Quality (DIN4762-DIN4768-ISO/4287/1); 3 points Flow
calibration certificate; FDA declaration of conformity (stainless
steel fitting only with EPDM seal)
Pressure/temperature diagram
A: Application range for complete device (sensor-fitting + transmitter)
Pressure
[bar]
Temperature [°C]
A ( T ype SE30 Ex)
A (Type 8030, 8032, 8034, 8035, 8036)
10
9
8
7
6
5
4
3
2
1
0
-30 -10 +10 +30 +50 +70 +90 +110
PVDF (PN10)
PVC (PN10)
PP a flow conditioner
to obtain the best results. The most important layouts that could lead to turbulence in the flow are shown below, together with the associated
prescribed minimum inlet and outlet distances determined according to the standard EN ISO 5167-1
DN = pipe diameter Flow direction -->
Control valve
50 x DN 5 x DN
40 x DN 5 x DN
25 x DN 5 x DN
20 x DN 5 x DN
18 x DN 5 x DN
15 x DN 5 x DN
2×90° elbow joint
50 x DN 5 x DN
40 x DN 5 x DN
25 x DN 5 x DN
20 x DN 5 x DN
18 x DN 5 x DN
15 x DN 5 x DN
Pipe diameter
expansion
50 x DN 5 x DN
40 x DN 5 x DN
25 x DN 5 x DN
20 x DN 5 x DN
18 x DN 5 x DN
15 x DN 5 x DN
2×90° elbow joint
3 dimensional
90° elbow joint
or T-piece
Pipe diameter
reduction
* For the 2014/68/EU pressure directive, the device can
only be used under following conditions (depending on
max. pressure, pipe diameter and fluid).
Type of fluid Conditions
Fluid group 1,
article 4, §1.c.i DN ≤ 25
Fluid group 2,
article 4, §1.c.i
DN ≤ 32 or
PN*DN ≤ 1000
Fluid group 1,
article 4, §1.c.ii
DN ≤ 25 or
PN*DN ≤ 2000
Fluid group 2,
article 4, §1.c.ii
DN ≤ 200 or
PN ≤ 10 or
PN*DN ≤ 500 outlet distances must be observed. According to the pipes design, necessary distances can be bigger or use

型号 117 是一种直动式升降式衔铁电磁阀，带有相应的塑料外壳和一个具有 PTFE 涂层的隔膜。此设备可无需电流借助弹簧力关闭。接通时，磁芯受到吸引，由此克服弹簧力。阀门特别适合流量很小的、液态或气态的侵蚀性介质。

For selecting the correct product please refer to the technical data, images and notes for proper use according to the data sheet.
