阿美特克AMETEKUS Gauge659压力表厂家价格
- 产地：深圳市
- 供应商：深圳市银飞电子科技有限公司
- 供应商报价：面议
- 标签：阿美特克AMETEKUS Gauge659压力表厂家价格
产品库
阿美特克AMETEKUS Gauge659压力表厂家价格
When safety is your top priority, AMETEK U.S. Gauge offers the new Model 659 Series SOLFRUNT Gauges.
阿美特克AMETEKUS Gauge659压力表厂家价格
| Accuracy Model 6592 (63 mm) | ±1.6% of full scale (Grade B) Model 6596 (100 mm): ±1.0% of full scale (Grade 1A |
| Pressure Range 63 mm | 30 inch Hg to 0 psi through 0 to 10,000 psi 100 mm: 30 inch Hg to 0 psi through 0 to 23,000 psi |
| Working Pressure Steady | 50% of full scale Over Range Protection: 125% of full scale |
| Working Temperature Ambient | -40°F to 140°F (-40°C to 60°C) Fluid -4°F to 176°F (-20°C to 80°C) |
| Filling Liquid | Glycerin, silicone, mineral oil |
| Pressure Connection | 316L stainless steel |
| Bourdon Tube | Model 6592 (63 mm): Less than or equal to 800 psi: C type Bourdon tube greater than or equal to 1000 psi: Helical type Bourdon tube Model 6596 (100 mm): Less than or equal to 1000 psi: C type Bourdon tube greater than or equal to 1500 psi: Helical type Bourdon tube |
| Case Pressure Relief | Safety back |
| Case and Bezel Ring | 304 stainless steel; bayonet type |
| Movement | 304 stainless steel |
| Window 63 mm | Polycarbonate (laminated shatter-resistant glass window optional) 100 mm: Laminated shatter-resistant glass window |
| Dial | White aluminum with black lettering |
| Pointer | Aluminum alloy, black painted |
These gauges are available in both 63 and 100 mm sizes, in panel mount and low mount configurations. The liquid fill minimizes the effect of these severe environments, protects the gauge internals, and provides continuous lubrication on the mechanism, all adding up to extended service life. Liquid filling also provides greater protection of the gauge internals from corrosive atmospheres.
Description
When safety is your top priority, AMETEK U.S. Gauge offers the new Model 659 Series SOLFRUNT Gauges. The Model 659 provides users with a solid-front and pressure-relieving back design in all stainless steel construction.US Gauge659压力表
