Ex AZM 415 20/2S A 无锡STEUTE现货Ex AZM 415 20/2S A防爆磁开关

Ex AZM 415 20/2S A防爆磁开关

EEx AZM 415 2Ö/2S A Ex AZM 415 20/2S A

IEC/EN 60947-5-1; EN 1088;

EN 50014; EN 50018;

EN 50019; EN 50281-1-1

Enclosure aluminium die casting, enamelled

Cover    steel, enamelled

Actuator/locking bolt  metal zinc/aluminium

Switch insert Ex 95

Protection class   IP 67 according to EN 60529

Contact material   silver

Switching system   slow action, NC contact with positive break

Switching elements change-over contact with double break Zb, galvanically separated contact bridges

Termination   M3 screw clamps

Cable section max. 2.5 mm2 (incl. conductor ferrules)

Cable entries 2 x M20 x 1.5 for cable section 5 … 9 mm

Cable length  -

Uimp 4 kV

Ui   250 V

Ithe 6 A

Ie/Ue    6 A/250 VAC; 40 mA/24 VDC

Utilisation category   AC-15

Max. fuse rating   6 A gL/gG D-fuse

Us   24 VDC

Magnet   100 % ED

Unlocking 100 % ED

Power consumption  max. 12 W

Ambient temperature    –20 °C … +55 °C

Mechanical life    > 1 million operations

Holding force F    max. 3500 N

Holding force of integrated ball catch    120 - 400 N, adjustable

Ex certification     II 2G EEx dem IIC T6,

II 2D IP67 T80°C

Approvals DMT 02 ATEX E 255 X
