标准 绿光DPSS激光器模块
- 型号：标准
- 产地：长春市
- 供应商：长春博盛量子科技产品贸易有限公司
- 供应商报价：面议
- 标签：绿光DPSS激光器模块
产品库
世界上zui小的绿光532nm激光器
| Model Number | SCL-CW-532-5.6MM-001 | SCL-CW-532-5.6MM-005 | SCL-CW-532-5.6MM-015 |
| Output Power CW, mW | 1 | 5 | 15 |
| Output Wavelength, nm | 532.43 | ||
| Beam Mode | TEM 00 | ||
| Beam Diameter, mm | 0.05 | ||
| Beam Divergence ( full angle), mrad | 6.5 | ||
| Operating Current, mA | ≤ 200 | ||
| Operating Voltage, V | <1.8 | ||
| Operating Temperature, °C | +10 + 35 | ||
| Residual IR ( 1064nm ), % | <0.5 | ||
| Polarization | >5 : 1 | ||
| Expected Operation Lifetime, hours | >4000 | ||
| Laser Head Dimensions, mm | ?5.6 x length 8.95 | ||
| Model Number | SCL-CW-532-9MM-100 | SCL-CW-532-9MM-150 |
| Output Power CW, mW | 100 | 150 |
| Output Wavelength, nm | 532.43 | |
| Beam Mode | TEM 00 | |
| Beam Diameter, mm | 0.12 | |
| Beam Divergence ( full angle), mrad | 8 | |
| Operating Current, mA | ≤ 1200 | |
| Operating Voltage, V | <1.8 | |
| Operating Temperature, °C | +10 + 35 | |
| Residual IR ( 1064nm ), % | <0.5 | |
| Polarization | >5 : 1 | |
| Expected Operation Lifetime, hours | >4000 | |
| Laser Head Dimensions, mm | ?9.0 x length 13.1 | |
